Factory Direct Sale Construction Hoist With High Quality

Product Introduction

  Construction hoist is widely used in the vertical transportation of personnels and materials. It ‘s a good indispensable transportation equipment in the area of industrial and civil buildings, bridges, large shaft.aAs a permanent or semi permanent, it can also be used for different occasions such as warehouse, tower and so on. Compared with the other lifting mechanism the product is stable, safe and reliable, without additional room.It has the advantages of convenient assembly and disassembly, handling flexibility strong advantages, especially in reducing the construction personnel's labor intensity, speed up the project progress, improve the work efficiency.

Product Feature.

  This kind machine has reasonable design, novel structure, stable operation, reliable safety device, convenient installation and maintenance, mainly has the following features:
1, the driving mechanism adopts three motor drive form, so that the gear rack is uniform, safe and stable.
2, to ensure the safe operation of the elevator, the circuit set the overload, speed limit and other safety switches, when the operation occurs in the above case, the elevator automatically to avoid accident. The door of the hanging cage is also limited to a switch, and when any door is opened, the suspension cage can not start or stop running immediately.
3, each cage is equipped with anti falling safety device, can effectively prevent cage falling, to ensure safe and reliable operation of the elevator.
4, elevator control system circuit is simple, easy to operate and maintenance, and reliable. During normal operation of the elevator, the hanging cage with a handle or a button control elevator operation, in any parking position can be stopped at any time, in the upper and lower terminal station, the upper and lower terminal limit switch control automatic parking, if the terminal limit switch for fault does not play a role, the lifter is provided the limit switches can be promptly cut off the power supply of the brake.
5, the steel structure design through scientific and rigorous calculation, achieve reasonable structure, reliable strength, light weight requirement.
6, the elevator can use the cage on the hanger to install or remove the guide frame. Convenient installation and disassembly of each part can be the rest of the parts can be easily replaced.

Spare Parts.

1- cage   2-rope pulley   3-lamp    4-roller    5-roller spanner 6-cable joint   7-cable joint    8-gate roller lower                   9-gaterroller upper    10-screw    11-nylon wheel                12-protect hook       13-mast section     14-rack 15-“J”screw

Spare Parts.

16-safety device   17-out operate box   18-safety device spanner   19-drop test operate box   20-3 phase switch    21-limint switch   22-motor 23-coupling 24-pinion 25-spring 26-adjustment unit 27-brake pad 28-jacket 29-rubber   30-brake disc     31-brake piece  32-electromagnet 33-rubber pad   34-reducing device 35-worm wheel          36-worm   37-oil seal   38-bearing   39-counter roller       40-worm gear fan

Spare parts.

41-creepage switch   42-overload   43-brake unit 44-drop test plug    45-transformer   46-contactor    47-PLC module   48-fan     49-thermal relay    50-belling                 51-calling system

Spare Parts.

52-master controller      53-emergency stop button          54-hander switch    55-bell switch     56-lamp switch       57-EL.lock     58-Hydraulic spring     59-water proof plug 60-annunciator     61-resistance     62-pipe joint
