PET Preform Injection Moulding Machine/Machinery(130T-400T)

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Guangzhou or Shenzhen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Product Type	Other, PET Preform
Place of Origin	Guangdong, China	Brand Name	Powerjet
Model Number	PET	Certification	CE

Product Description

Specifications

PET preform injection machinery
PET injection moulding machine
PET preform injection moulding machine

PET preform injection machinery
PET injection moulding machine
PET preform injection moulding machine
Special PET screw Injuction moulding machine

Servo motor
Variable pump

Shot weight:300g-4000g

Clamping force: 130T-400T

Space between bars: 410*410-740*720 mm

Opening stroke:400-710 mm

Technical Parameter
Description	Unit	PET-350V2	PET-450V2	PET-500V2	PET-800V2	PET850V2	PET-1200V2	PET1205V2	PET-1500V2	PET-1505V2	PET2050V2	PET-2100V2	PET-3100V2
Injection Unit
Screw Diameter	mm	46	52	52	60	60 63	67	67	75	75	83	83	95
Screw L/D Ratio		22	22	22	22	22	22	22	22	22	22	22	22
Shot Volume	cm3	333	435	435	693	764	987	987	1303	1303	1840	1840	2694
Shot Weight(@PS1.05)	g	313	409	409	951	718	927	927	1224	1224	1729	1729	2531
Shot weight(@PET1.3)	g	387	507	507	806	806 889	1150	1150	1515	1515	2140	2140	3134
Shot weight(@PP0.9)	g	268	351	351	558	615	795	795	1049	1049	1482	1482	2170
Screw stroke	mm	200	205	205	245	145	280	280	295	295	340	340	380
Max.screw rotary speed	rpm	180	180	180	170	170	160	160	170	170	106	118	110
Clamping Unit
Clamping Force	KN	1300	1300	1600	1600	2000	2000	2880	2880	3300	2880	3300	3300
Opening Stroke	mm	400	400	440	440	490	490	550	550	600	550	600	580
Max daylight:	mm	820	820	940	940	1040	1040	1160	1160	1300	1160	1300	1280
Space between Bars(H*V)	mm*mm	410*410	410*410	460*460	460*460	510*510	510*510	610*610	610*610	670*670	610*610	670*670	660x860
Movable platen size(H*V)	mm*mm	610*620	610*620	705*705	705*705	775*755	775*755	850*850	850*850	985*985	850*850	985*985	940x1140
Max. Mold Height	mm	420	420	500	500	550	550	610	610	700	610	700	700
Min. Mold Height	mm	150	150	160	160	230	230	280	280	300	280	300	300
Ejector Stoke	mm	125	125	145	145	160	160	175	175	180	175	180	180
Ejector Force	KN	60	60	75	75	99	99	111	111	184	111	184	184
Ejector-back force	KN	36	36	55	55	770	775*755	77	77	115	77	115	115
Number of ejector pins		4+1	4+1	4+1	4+1	6+1	6+1	5+1	5+1	12+1	5+1	12+1	8+1
Power Unit
Hydraulic System Pressure	Mpa	17.5	17.5	17.5	17.5	17.5	17.5	17.5	17.5	17.5	17.5	17.5	17.5
Pump Motor Power	KW	11	15	15	18.5	18.5	22	22	30	30	30	37	45
Heater Power	KW	10	12.5	12.5	15	15	16.5	20	20	20	20	28	36
Total current	A	65	86.8	86.8	104.1	104.1	117.5	147.5	147.5	147.5	147.5	197	253.6
General
Oil Tank Capacity	L	200	200	280	280	420	420	560	560	560	650	650	800
Machine Weight	Ton	3.6	36	4.5	4.9	6.4	6.4	8.8	8.8	10.5	10.6	10.6	20
Machine Dimensions(LWH)	mmm	4.51.21.8	4.51.21.8	5.31.31.8	5.31.31.8	6.01.42.1	6.01.42.1	6.51.532.2	6.51.532.2	7.1*1.62.2.3	7.11.622.3	7.11.622.3	6.8x1.62x2.5
