WPW Gearing Arrangement Gearbox Gear Reducer
- Shanghai/Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Gearing Arrangement | Worm | Output Torque | 6N.m | |
| Rated Power | 0.12kw | Input Speed | 1500rpm | |
| Output Speed | 150rpm | Place of Origin | Zhejiang, China | |
| Model Number | WPWDS40 1:10 | Brand Name | Ybang |
Product Description
WPW Gearing Arrangement Gearbox Gear Reducer
Main Products:
Obang Machinery, specialized in various speed reducers, including R, F, K, S series helical geared
motor, BH series helical gear units, BB series bevel-helical gear unit, T series spiral bevel gear
steering device, WP series worm gear speed reducer.
There are three types of WP series worm gear speed reducer:
1. Single Speed Reducer,
2. Double Speed Reducer,
3. Universal Speed Reducer.
Type: | WP series Single-stage Speed Reducer-Iron Worm Gear Box |
Model: | WPWDS40 1:10 |
Others: | 40,60,70,80,100,120,135,147,155,175,200,250 |
Color: | Blue/Green or on customer request |
Material: | HT200 |
Input power: | 0.12kw(Under the case of input speed 1500rpm) |
Ratio: | 10 |
Output torque: | 6n.m |
Bearing: | C&U, NSK, SKF or specified |
Seal: | CTY, CFW, SKF or specified |
Product features: | It adopts American technology with durability, stable transmission, large carrying capacity, low noise, compact structure, large transmission ratio and wide power. |
Application areas: | Textile printing and dyeing, rubber and plastic machinery, building materials machinery, environment protection machinery, lifting machinery, food packaging, metallurgical machinery, petrochemical industry, stage machinery and new energy field. |
Lubricant: | Synthetic |
Warranty: | 1Year |
Design characteristics:
1.Use low-carbon cast iron cementation processing completely.
2.The gear and the gear shaft precision is high.
3.Small volume , High torque.
4.Can be 2 or 3 sets of gear reducer composed of multi-level, to get great gear ratio.
5.After 300-hour operation, please change the oil, and flush the gear uint with suitable detergents.
(1) With excellent quality and Reasonable price
(2) Promise to delivery on time
(3) Safe, reliable, economical and durable
(4) Stable transmission, quiet operation
(5) High heat-radiating efficiency, high carrying ability
(6) Every product must be tested before sending
1. How to find the model I need?
CS: If bought this product before, check the nameplate, if not, show us the details, for example, motor power, output peed or ratio.
2. Is it possible to produce zero backlash product?
CS: Actually, no company can produce zero backlash product. Our standard is under 0.1
3. Does your company support customized product?
CS: Professional R&D dept will try to meet your requirement.
4. What’s your quality assurance
CS: In addition to the internal testing , we provide one year guarantee. Our mission: Any problems during running, firstly solve it, then discuss who will be be responsible for this issue.
