Non-woven Polyester Mat/160g Long Fiber Polyester Mat for SBS/APP Waterproof Membrane
- QINGDAO
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | HUIYUAN | |
| Model Number | HY-Z |
Product Description
Specifications
non-woven polyester mat/160g long fiber polyester mat for SBS/APP waterproof membrane1.Use:SBS/APP
2.ISO9001 CE
non-woven polyester mat/160g long fiber polyester mat for SBS/APP waterproof membrane
This product is adopted super strength polyester clip as material. It is finished through three procedures: spinning, needle punching and fixing form. It is a kind of new material to produce modified bitumen waterproof membrane. It is a new favorite of the waterproofing industry and the construction industry.
Main properties:
1. Much stronger tensile strength and elongation.
2. Much better heat stability and tearing resistance ability
3. Much stronger puncture resistance and impregnation ability.
4. Much stronger Corrosion-resistant, anti-aging ability.
Specifications | ||||||||||||
Item | Unit | 100g/m2 | 120g/m2 | 140g/m2 | 160g/m2 | 180g/m2 | 200g/m2 | 220g/m2 | 250g/m2 | 280g/m2 | 320g/m2 | |
Length | m | 1000 | 1000 | 1000 | 1000 | 800 | 800 | 800 | 800 | 800 | 600 | |
Thickness | mm | 0.4±0.2 | 0.5±0.2 | 0.6±0.2 | 0.7±0.2 | 0.8±0.2 | 0.9±0.2 | 1.0±0.2 | 1.2±0.2 | 1.4±0.2 | 1.8±0.2 | |
Width | mm | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | |
Moisture Content | % | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.4 | |
Uneven Rate | % | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | ≤±0.6 | |
Shrinkage at 200°C | % | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | ≤±2 | |
Tensile Strength | MD | N/5cm | ≥330 | ≥370 | ≥400 | ≥430 | ≥480 | ≥530 | ≥600 | ≥650 | ≥800 | ≥1050 |
CD | N/5cm | ≥310 | ≥350 | ≥380 | ≥410 | ≥460 | ≥510 | ≥580 | ≥600 | ≥800 | ≥1050 | |
Elongation at Break | MD | % | 24 | 23 | 27 | 29 | 30 | 30 | 30 | 35 | 40 | 50 |
CD | % | 28 | 26 | 28 | 32 | 33 | 33 | 33 | 37 | 45 | 55 | |
Tearing Strength | MD | N/5cm | ≥50 | ≥70 | ≥80 | ≥90 | ≥100 | ≥140 | ≥150 | ≥160 | ≥180 | ≥220 |
CD | N/5cm | ≥50 | ≥70 | ≥80 | ≥90 | ≥100 | ≥140 | ≥150 | ≥160 | ≥180 | ≥220 | |
