nonwoven geotextile 100gsm

FOB Price

USD $0.2 - $0.5 / Square Meter

5000 Square Meters(Min.Order)

Port FOB: QINGDAO
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	HUIYUAN
Model Number	HY-Z		Material	Other, polyester fiber

Product Description

Specifications

nonwoven geotextile 100gsm
1)high quality geotextiles
2)ISO9001: 2008 certified
3)Short or Long fiber needle punched

nonwoven geotextile 100gsm

The product is widely used engineering cloth. It has many functions as follows: water impermeability, filtering, draining, isolating, reinforcing, protecting, sealing and so on.

Main Properties:

1. It is used high strength polyester clip as material. It is finished through two procedures: spinning and needle punching. The comprehensive carrying capacity is further enhanced.

2. Strong tensile strength, anti-aging and long service life.

3. It is not easy to deform, decompose and differentiation.

4. Excellent anti-acid and anti-alkali ability, strong anti-moth and anti-mould ability.

5. Excellent permeability.

6. Excellent high and low temperature resistance. It can adapt to various environment.

Item		Unit	Specifications
Weight Per Unit Area		g/m²	100	150	200	250	300	350	400	500	600	800
Thickness		mm≥	1.1	1.3	1.7	2.1	2.4	2.7	3.0	3.6	4.1	5.0
Tensile Strength	MD	kN/m≥	2.8	4.7	6.7	8.2	9.8	11.3	12.8	16.4	19.5	25.8
Tensile Strength	CD	kN/m≥	3.0	5.2	8.0	9.8	11.7	13.6	15.4	19.7	23.4	31.2
Elongation at Break	MD	%	91	89	88	85	75	60	65	59	61	59
Elongation at Break	CD	%	87	84	82	79	82	71	59	58	65	62
Tearing Strength		kN	0.10	0.12	0.16	0.20	0.24	0.28	0.33	0.42	0.46	0.54
CBR Bursting Strength		kN≥	0.5	0.7	1.1	1.3	1.7	2.0	2.3	2.9	3.5	4.4
Equivalent Aperture(O95)		mm	0.15	0.14	0.13	0.12	0.11	0.10	0.09	0.08	0.07	0.07
Vertical Permeability Coefficient		cm/s	(6-0.2)×10^-1
