Home > Products > IDC Connectors > 1.27MM Pitch IDC Socket Connectors Wire Harness
1.27MM Pitch IDC Socket Connectors Wire Harness
- Hongkong
- T/T L/C D/P D/A
You May Like
-
2.00mm Pitch Box Header Connectors Straight Good Quality Wafer
-
2.00mm Pitch IDC Socket Flat Cable Connectors
-
0.8mm Pitch IDC Connectors JST Replacement
-
0.60mm Pitch Electrical IDC Connectors JST Substitute
-
IDC 1.27mm Pitch Wire to Board Cable Connectors
-
Manufacture of 2.54mm Pitch IDC Connectors for Automotion
Product Details
| Place of Origin | Guangdong, China | Brand Name | SWB | |
| Model Number | 9127HI | Type | Other |
Product Description
1.27MM Pitch IDC socket Connectors for Storage for Automotive
SPECIFICATIONS:
Voltage Rated: 500V AC/DC
Current Rated: 1A AC/DC Max
Withstand voltage: 1000V AC/minute
Insulation resistance: 1000MΩ min
Contact resistance: 20 MΩ max
Operation temperature: -40℃~+105°C
Wire Range:AWG#32
Item | Part No | Material | Poles | Package |
Housing | 9127HI-XX-PTRE | PBT UL94V-0 | 04-26 | 100 Pcs/tray |
1 Packaging: Useing strong bags/boxes/cartons for package to reduce the damage during the shipments. Tape and reel packing, Clamshell packing,Pallet packing etc are available.
2 Delivery Method: by sea, by air, or express such as DHL/TNT/UPS etc.
3 Delivery Time: normally 7-14days, could be negotiable when order is urgent.
1 fully-Inspection - Products are 100% inspected before shipment
2 In case of quality discrepancy or quantity discrepancy, we will do replenishment immediately, or other better methods after negotiation, to make sure our customers could be satisfied well.
3 Solution - Find the problems, make an effective improvement, and impose more strict quality control.
4 Long term after sell service to keep customer satisfied.
