380/ 220V Voltage 90kw 7bar Dry Air Compressor

FOB Price

US$ 8,400 - 8,700 / Piece

1 Piece(Min. Order)

Port Guangzhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary
Configuration	Stationary	Power Source	AC Power
Lubrication Style	Lubricated	Mute	No
Place of Origin	Guangdong, China	Brand Name	Tuowei
Model Number	SGD 90	Voltage	380/220V
Dimension(LWH)	12001600400mm	Weight	2000kg
Certification	CE Certification	Warranty	1 Year
After-sales Service Provided	Overseas third-party support available

Product Description

380/ 220V voltage 90kw 7bar dry air compressor

Product Description

Advantages

-Simple, Compact Design:
Sturdy construction with few moving parts, easy to access and maintain ,easy to replace parts, very reliable and durable.

-Direct Axial Coupling to the Motor:
Direct coupling is possible because the high compression ratio permit slow rotation speeds, eliminating the need for transmission or gears. Fewer parts, mean slower energy dissipation and simplified maintenance.

-Low Rotation Speeds:
Lower speeds reduce vibration, thus diminishing noise and wear, lowering temperature and eliminating the need for foundations.

-Low Cycle Temperature:
Lower temperatures reduce wear, coolant consumption and leakage caused by distension of parts.Less energy is needed for cooling, and the purity of delivered air is enhanced.

-Low Need for Maintenance:
With fewer parts suffering little wear, single-stage rotary units offer cleaner and more reliable operation, significantly reducing maintenance needs.

Belt Drive Screw Air Compressor
Model		SG 06	SG 08	SG 11	SG 15	SG 18	SG 22	SG 30	SG 37	SG 45	SG 55	SG 75	SG 90	SG 110	SG 132	SG 160
Capacity / Pressure		0.85 / 0.7	1.2 / 0.7	1.7 / 0.7	2.4 / 0.7	3.1 / 0.7	3.8 / 0.7	5.2 / 0.7	6.4 / 0.7	8.0 / 0.7	10.5 / 0.7	13.6 / 0.7	16.3 / 0.7	20.8 / 0.7	24.8 / 0.7	28.5 / 0.7
(m³/min/Mpa)		0.78 / 0.8	1.1 / 0.8	1.6 / 0.8	2.2 / 0.8	2.9 / 0.8	3.5 / 0.8	5.0 / 0.8	6.1 / 0.8	7.7 / 0.8	9.8 / 0.8	13.3 /0.8	16.0 / 0.8	20.6 / 0.8	24.0 / 0.8	27.0 / 0.8
		0.65 / 1.0	0.95 / 1.0	1.4/ 1.0	2.0 / 1.0	2.7 / 1.0	3.2 / 1.0	4.3 / 1.0	5.7 / 1.0	7.0 / 1.0	8.7 / 1.0	11.6 / 1.0	14.6 / 1.0	17.0 / 1.0	20.6 / 1.0	23.2 / 1.0
		0.5 / 1.3	0.8 / 1.3	1.2 / 1.3	1.7 / 1.3	2.2 / 1.3	2.9 / 1.3	3.7 / 1.3	5.1 / 1.3	5.8 / 1.3	7.5 / 1.3	9.8 / 1.3	12.3 / 1.3	14.2 / 1.3	16.5 / 1.3	19.7 / 1.3
Motor	Power (KW)	5.5	7.5	11	15	18.5	22	30	37	45	55	75	90	110	132	160
Motor	Horsepower	7.5	10	15	20	25	30	40	50	60	75	100	125	150	180	220
Noise dB(A)		63±2	65±2	68±2	68±2	69±2	69±2	69±2	70±2	72±2	73±2	75±2	75±2	75±2	75±2	75±2
Air Outlet		G3/4	G3/4	G3/4	G3/4	G1 1/4	G1 1/4	G1 1/4	G1 1/2	G1 1/2	G2	G2	G2	DN65	DN65	DN80
Pipe Diameter		G3/4	G3/4	G3/4	G3/4	G1 1/4	G1 1/4	G1 1/4	700	700	1230	1350	1650	2500	2600	3150
Weight (kg)		200	200	335	350	500	500	560	1200	1200	1500	1550	1700	2380	2380	3000
Housing dimension	L(mm)	750	750	950	930	1100	1100	1100	1000	1000	1150	1270	1550	1650	1650	1800
	W(mm)	650	650	770	770	850	850	850	1420	1420	1500	1500	1600	1900	1900	2050
	H(mm)	830	830	1100	1100	1300	1300	1300	180	191	320	330	400	450	450	500
Cooling air Flow		23	23	91	91	100	100	100	-	3	5	5	7	10	10	10
( m³.min)		23	23	91	91	100	100	100	-	23	23	23	23	100	100	100

Direct Drive Screw Air Compressor
Model		SGD 22	SGD 30	SGD 37	SGD 45	SGD 55	SGD 75	SGD 90	SGD 185	SGD 220	SGD 250	SGD 315	SGD 355	SGD 400	SGD 450	SGD 500	SGD 560	SGD 630
Capacity / Pressure		3.8 / 0.7	5.2 / 0.7	6.4 / 0.7	8.0 / 0.7	10.5 / 0.7	13.6 / 0.7	16.3 / 0.7	32.5 / 0.7	38.6 / 0.7	43.9 / 0.7	56.0 / 0.7	64.0 / 0.7	74.0 / 0.7	85.0 / 0.7	93.0 / 0.7	105.0 / 0.7	125.0 / 0.7
(m³/min / Mpa)		3.5 / 0.8	5.0 / 0.8	6.1 / 0.8	7.7 / 0.8	9.8 / 0.8	13.3 / 0.8	16.0 / 0.8	30.2 / 0.8	36.4 / 0.8	42.5 / 0.8	53.0 / 0.8	62.0 / 0.8	72.0 / 0.8	82.0 / 0.8	91.0 / 0.8	100.0 / 0.8	120.0 / 0.8
		3.2 / 1.0	4.3 / 1.0	5.7 / 1.0	7.0 / 1.0	8.7 / 1.0	11.6 / 1.0	14.6 / 1.0	27.0 / 1.0	33.1 / 1.0	38.8 / 1.0	49.0 / 1.0	57.6 / 1.0	62.0 / 1.0	70.0 / 1.0	82.0 / 1.0	85.0 / 1.0	100.0 / 1.0
		2.9 / 1.3	3.7 / 1.3	5.1 / 1.3	5.8 / 1.3	7.5 / 1.3	9.8 / 1.3	12.3 / 1.3	22.5 / 1.3	30.5 / 1.3	34.6 / 1.3	43.0 / 1.3	49.0 / 1.3	56.5 / 1.3	60.5 / 1.3	68.0 / 1.3	-	-
Motor	Power (KW)	22	30	37	45	55	75	90	185	220	250	315	355	400	450	500	560	630
Motor	Horsepower	30	40	50	60	75	100	125	250	300	340	420	480	540	600	670	750	840
Noise dB(A)		69±2	69±2	70±2	72±2	73±2	75±2	75±2	78±2	78±2	78±2	80±2	82±2	83±2	84±2	86±2	88±2	88±2
Air Outlet		G1 1/4	G1 1/4	G1 1/2	G1 1/2	G2	G2	G2	DN80	DN100	DN100	DN125	DN125	DN150	DN150	DN200	DN200	DN200
Pipe Diameter		G1 1/4	G1 1/4	720	900	1350	1400	1700	3330	4300	4600	6500	7000	7500	DN150	DN200	DN200	DN200
Weight (kg)		520	650	1500	1500	1650	1800	2000	3000	3000	3000	3800	3800	4200	8100	8500	9000	9000
Housing dimension	L(mm)	1300	1500	1000	1000	1170	1200	1200	1800	1980	1980	2280	2280	2200	4650	4650	4650	4650
	W(mm)	850	1000	1300	1300	1440	1500	1600	2050	1900	1900	2248	2248	2350	2050	2150	2150	2150
	H(mm)	1150	1300	180	191	320	330	400	600	900	900	-	-	-	2120	2120	2120	2120
Cooling air Flow		100	100	-	3	5	5	7	12	20	20	30	30	35	35	35	35	35
( m³.min)		100	100	-	23	23	23	23	100	145	145	200	200	250	250	250	250	250

Variable Speed Screw Air Compressor
Model		SGV 06	SGV 08	SGV 11	SGV 15	SGV 18	SGV 22	SGV 30	SGV 37	SGV 45	SGV 55	SGV 75	SGV 90	SGV 132	SGV 160	SGV 185	SGV 220	SGV 250
Capacity/Pressure		0.85 / 0.7	1.2 / 0.7	1.7 / 0.7	2.4 / 0.7	3.1 / 0.7	3.8 / 0.7	5.2 / 0.7	6.4 / 0.7	8.0 / 0.7	10.5 / 0.7	13.6 / 0.7	16.3 / 0.7	24.8 / 0.7	28.5 / 0.7	32.5 / 0.7	38.6 / 0.7	43.9 / 0.7
(m³.min/Mpa)									6.1 / 0.8	7.7 / 0.8	9.8 / 0.8	13.3 / 0.8	16.0 / 0.8	24.0 / 0.8	27.0 / 0.8	30.2 / 0.8	36.4 / 0.8	42.5 / 0.8
		0.78 / 0.8	1.1 / 0.8	1.6 / 0.8	2.2 / 0.8	2.9 / 0.8	3.5 / 0.8	5.0 / 0.8	5.7 / 1.0	7.0 / 1.0	8.7 / 1.0	11.6 / 1.0	14.6 / 1.0	20.6 / 1.0	23.2 / 1.0	27.0 / 1.0	33.1 / 1.0	38.8 / 1.0
		0.65 / 1.0	0.95 / 1.0	1.4 / 1.0	2.0 / 1.0	2.7 / 1.0	3.2 / 1.0	4.3 / 1.0	5.1 / 1.3	5.8 / 1.3	7.5 / 1.3	9.8 / 1.3	12.3 / 1.3	16.5 / 1.3	19.7 / 1.3	22.5 / 1.3	30.5 / 1.3	34.6 / 1.3
		0.5 / 1.3	0.8 / 1.3	1.2 / 1.3	1.7 / 1.3	2.2 / 1.3	2.9 / 1.3	3.7 / 1.3	37	45	55	75	90	132	160	185	220	250
Motor	KW	5.5	7.5	11	15	18.5	22	30	50	60	75	100	125	180	220	250	300	340
Motor	HP	7.5	10	15	20	25	30	40	70±2	72±2	73±2	75±2	75±2	75±2	75±2	78±2	78±2	78±2
Noise dB(A)		65±2	66±2	68±2	68±2	69±2	69±2	69±2	G1 1/2	G1 1/2	G2	G2	G2	DN65	DN80	DN80	DN100	DN100
Pipe Diameter		G3/4	G3/4	G3/4	G3/4	G11/4	G11/4	G11/4	760	845	1350	1420	1750	3100	3500	3500	4500	4800
Weight(kg)		210	210	365	365	525	550	610	1300	1300	1650	1700	1700	2550	3000	3000	3250	3250
Dimension	L(mm)	750	750	950	950	1100	1100	1100	1000	1000	1350	1550	1550	1650	1800	1800	1980	1980
	W(mm)	650	650	800	800	1000	1000	1000	1350	1350	1500	1600	1600	2000	2050	2050	1900	1900
	H(mm)	825	825	1130	1130	1240	1240	1240	180	191	320	330	400	450	500	600	900	900
Cooling air Flow		23	23	91	91	100	100	100	-	3	5	5	7	10	10	12	20	20
( m³/min)									-	23	23	23	23	100	100	100	145	145
