Nickel Alloy UNS N06022 Flange

corrosion resistance nickel alloy UNS N06022

Hastelloy C-22

Common Trade Names: Hastelloy C22, Inconel 22, Nickel 22, Alloy 22, Nicrofer 5621.

Hastelloy C-22 Alloy 22 (UNS N06022; W. Nr. 2.4602; NiCr21Mo14W) is a fully austenitic advanced corrosion-resistant alloy that offers resistance to both aqueous corrosion and attack at elevated temperatures. This alloy provides exceptional resistance to general corrosion, pitting, crevice corrosion, intergranular attack, and stress corrosion cracking. Alloy 22 has found numerous applications in the chemical/petrochemical processing, pollution control (flue gas desulfurization), power, marine, pulp and paper processing, and waste disposal industries.

Alloy 22 is nickel-base and typically contains 22% chromium, 14% molybdenum, and 3% tungsten. Iron is normally limited to less than 3%. The alloy’s high content of chromium gives it good resistance to wet corrosion by oxidizing media (e.g., nitric acid and ferric and cupric salts). Its contents of molybdenum and tungsten give the alloy resistance to wet reducing media (e.g., sulfuric and hydrochloric acids). Alloy 22 exhibits excellent resistance to corrosive attack by seawater under stagnant and flowing conditions.

At elevated temperatures, the high chromium level of Hastelloy C-22 Alloy helps it resist oxidation, carburization, and sulfidation. Since it is nickel-base, alloy 22 resists high temperature attack by halides (e.g., chlorides and fluorides). With these attributes, the alloy is widely used to protect steel tubes and other components in coal-fired and waste-to-energy boilers.

Available Product Forms:
Rod, bar, forgings, wire, plate, sheet, strip, pipe, tube, pipe fittings.Flanges, Forged fittings, valve parts.

Specifications

Hastelloy C-22  Alloy is designated as UNS N06022 and Werkstoff Nr. 2.4602. It is listed in NACE MR-01-75..

Rod, Bar, Wire and Forging Stock: ASTM B564, ASTM B472, ASTM B574
Plate, Sheet and Strip: - ASTM B 575;

Pipe and Tube: - ASTM B622.

Pipe fittings: ASTM B366 WPHC22.

flanges, Forged fittings, valve parts: ASTM B462

Chemical Composition

Nickel.......................................................................Balance
Chromium....................................................................20.0-22.5
Molybdenum .................................................................12.5-14.5
Iron .........................................................................2.0-6.0
Tungsten .....................................................................2.5-3.5
Cobalt ......................................................................2.5 max.
Vanadium....................................................................0.35 max.
Carbon.....................................................................0.015 max.
Manganese ..................................................................0.50 max.
Sulfur .....................................................................0.02 max.
Silicon ....................................................................0.08 max.
Phosphorus .................................................................0.02 max.

mechanical property:

specifications:

we are professional manifacturer focus on corrosion resistance nickel alloy UNS N06022 ,any question pls feel free to send us inquires.
