Home > Products > For coaxial cables > Aluminium foil in spool packaging
Aluminium foil in spool packaging
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Tianhong | |
| Model Number | AL+PET | Type | Insulation Film | |
| Material | PET | Application | High Temperature | |
| Rated Voltage | min 1 KV | Tensile Strength | ≥80 Mpa |
Product Description
Specifications
1.Widely used in shielding for telecommunication cables;2.For insulation materials;
3.We are manufacturer;
1. Application
1.For wire cables;
2.For insulation materials;
3.For telephone lines;
4.We are manufacturer;
5.Can supply SGS,Certificate of original,MSDS,Test report,ect;
2. Feature
Good insulativity and shielding effectiveness to reduce attenuation, complying with RoHS standard.
3. Dimensions
Name | Aluminium Polyester Foil(Polyester=Mylar=PET) |
Thickness | 20u-150u |
Width | 5mm-1000mm |
Inner diameter | 38mm(1.5in) or 53.5mm(2.1in) or 76mm(3.0in) |
Outer diameter | 250mm-650mm |
Color | Silver,Blue,Golden |
Name:AL+PET |
|
|
|
Structure | Thickness(mic) | Weight(g/m2) | Yield(m2/kg) |
AL9+ PET12 | 23mic | 43 | 23 |
AL9 +PET15 | 26mic | 48 | 21 |
AL9 +PET19 | 30mic | 54 | 19 |
AL9 +PET23 | 34mic | 60 | 17 |
AL12 +PET12 | 26mic | 52 | 19 |
AL12 +PET15 | 29mic | 56 | 18 |
AL12 +PET19 | 33mic | 32 | 16 |
AL12 +PET23 | 37mic | 67 | 15 |
AL12 +PET36 | 50mic | 87 | 12 |
4.Note
Accept orders of foils with different thickness, length and width.
Copper color
Silver color
Blue color
