Home > Products > Slitting Machine& Bending&Punching machine > Pipe Curving Machine Metal Sheet Curving Machine
Pipe Curving Machine Metal Sheet Curving Machine
- Xingang Tianjin
- T/T
You May Like
Product Details
| Condition | New | Type | Other, Arching Machine, Curving | |
| Tile Type | Steel | Use | Roof | |
| Production Capacity | 8-12 | Place of Origin | Hebei, China | |
| Brand Name | FX Auto crimping curved roll forming machine | Model Number | curving | |
| Power(W) | 5.5KW | Voltage | 380V | |
| Dimension(L*W*H) | 2.1x 1.9x 1.5 | Weight | 1.5t | |
| Certification | CE | Warranty | one year, 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
@alang@
Application: the color steel sheet is used for roof panel together with building roof, wall of factory, warehouse, garage, gymnasium, exhibition center, cinema,theatre, e ct. It has many advantages, such as easy installation short building period, beauty, light weight but high strength
We Do Best, About Machine
We Do Details
♥ Machine parameters
| Thickness of middle plate | 20mm |
| Diameter of shaft(solid shaft ) | 70mm |
| Material of shaft (solid shaft) | (high grade) 45#steel ,quenching and tempering treatment |
| Material of roller | 45# steel |
| Reducer | 3#cycoid reducer (high grade) |
| Power of main motor | 4KW |
| Line speed | about 9m/min |
| Voltage | 380v/50HZ/3phase |
| Apprearnce size | 2.1m(length)*0.8m(width)*1.4m(height) |
| Electrically controlled system | entire machine controlled by PLC |
| Electric parts | Delta |
We Do Standard
♥ Control station
Computer Is Used To Control Length And Quantity.
Machine Will Cut To Length And Stop Automatically.
Length Accuracy Can Be Adjust Easily
Because of the long trip and your super trust, we will make sure the machine can be appeared in front of you in fully good condition, you will fall in love with it with first glimpse.
After finishing the machine ,will inform customer come for inspection.If customer didn't have time for inspection,will take photo or video for confirm.After the machine arrival the customer's company,if need,Engineer can installing to factory
Thanks very much for your time, welcome to contact Feixiang , we are with you within 24 hours.
We want to know following information.
1), What is the exact profile you want to produce?
2), What kind of material you will use, such as steel or aluminium, max coil weight, thickness?
3), What kind of decoiler and stacker you need?
Pls contact us as below informaiton,hope can cooperate,thanks advance.
