Downspout Forming Machine And Curving Machine

FOB Price

US$ 8,500 - 90,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	XINGBO
Model Number	furring		After-sales Service Provided	Engineers available to service machinery overseas

Downspout forming machine and curving machine
1.CE;SGS;ISO9001:2008 certificate
2.high strength long time
3.running steadily

Downspout forming machine and curving machine

Product Description

1. Profile	1.thickness: 0.45mm 2.size: a=24mm
2. Process flow	Decoiling--feeding---levelling--forming---measuring---cutting---production
3. Decoiler	Manual decoiler il inner diameter: 450-700mm il max width: 600mm 3.max carrying capacity: 1500kg
4.Forming device	1. Shaft material & rollers material&shaft diameter 45# steel adjustable treatment ;45# steel, polished, plate of chrome 0.05mm; 60mm 2.Rollers; 9 steps 3. Transport; chain drive 4. Forming speed; 6-10m/min 5. Motor; 3kw
5. Cutting device	1). Material: blade, puncher and mold material: Cr12 steel with quenched treated 60-62 2).Cutting system: advanced hydraulic drive, automatic cutting after forming, no distorting or wasting, high level safety factor.
6.Controlling device	1. screen: text screen from Taiwan 2. PLC: Taida DVP14ES from Taiwan 3. coder: ENC-1-1-1T-24 from South Korea
7. Hydraulic	1. Advanced hydraulic system from Taiwan 2. Power: 3kw
8. Spare parts	1. easy damaged parts: conk 2 pcs, fuse-link 4 pcs 2. rubber mat 1 pcs; 3. bolt spanner 1 pcs

Hebei Feixiang Roll Forming Machinery Co., Ltd.: Contact nameSam Li
Chat Now; Phone86-317-5569916 8297121; AddressNo. 88, Yingbin Road, Industrial Development Zone
