Wall and floor tiles making machine
- 6 Set / Sets per Month
- tianjin
- T/T
You May Like
-
Roll making equipments roll forming machine for cold steel floor deck
-
Feixiang machinery steel floor board roll forming machine
-
FX metal steel sheet decking floor roll forming drawing machine
Quality Choice
-
Quality hydraulic drive floor decking forming machine
-
Floor deck roll forming line for india market
-
Roll making machine series floor decking plate machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Steel | Use | Roof | |
| Production Capacity | 10m/min | Place of Origin | Hebei, China | |
| Brand Name | FeiXiang | Model Number | wall and floor tiles making machine | |
| Power(W) | 7.5kw | Voltage | as client's requirement | |
| Dimension(L*W*H) | 7*1.5*1.6m | Weight | 7tons | |
| Certification | CE ISO | Warranty | 365 days | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Wall and floor tiles making machine
Technical specifications
Meterial :#45 steel
package: simple waterproof
The min order:one set
Freight way: container
Term of payment: T/T
Strong point: debuging all the world, the best price
1.The chart of process flow:
Decoiling--active feeding---forming---measuring lengh---cutting---product to stand
2.Main equipment:
Decoiler,main forming machine,hydraulic cutting,electric system(plc),hydraulic system,product stand.
3.Technical parameters
1)Profile
A.thickness:0.3--0.8mm
B.Feeding width:1000mm
2)inner tight decoiler
il inner diameter:450mm--700mm
B.max width of coiling:1200mm
C.max weight of loading:5000kg
3)main forming machine
A.Shaft material:45# steel,bearing steel outer diameter 85mm
B.Main motor power:5.5kw
C.Forming speed:8--10m/min
D.Voltage:380v,50hz
E.Roller station:11
4)cutting system
A.hydraulic cutter
B.Blade and mould material:Cr12 steel with quenched treated 60-62
Cutting system advanced hydraulic drive,after automatic cutting after forming.no
5)control system
A.PLC: taida form Taiwan
B.Coder:from south korea
