Home > Products > Filling Machine > GZD100-2 Digital Control Liquid Filling Machine
GZD100-2 Digital Control Liquid Filling Machine
- NINGBO
You May Like
Product Details
| Condition | New | Application | Chemical, Food, Other, Chemical, Food, Machinery & Hardware | |
| Packaging Type | Bottles, Cans | Packaging Material | Other, Liquid | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220/110V 50/60Hz | Power | 300W | |
| Place of Origin | Zhejiang, China | Brand Name | zhonghuan | |
| Model Number | GZD100-2 | Dimension(L*W*H) | 3CBM | |
| Weight | 160KGS | Certification | GMP | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Double Heads Digital Filling Machine
Description:
* The Digi-Fil uses a gear pump concept as metering device to fill correct amounts
* Of gels or liquids into containers.
* The volume , speed, the time between of filling can be designed.
* Each filling can be fast first and slow later, bubble can be eliminated.
* Human interface is achieved using a combined keypad and LCD display configuration.
* 20 sizes data can be stored.
* Pump unit easily dismantled for cleaning.
* Can be extend to use in conveyor on line.
Main Technical Parameters:
Model | BNSZD100/2 (2 Unit Online) |
Volume | 10ml-Infinity |
Accuracy | 0.5-1% |
Filling Speed | 100ml 40P/min 300ml 30P/min 1000ml 18P/min |
Supply Power | 1P 220V 50-60Hz 1200W |
Air | 5-6Kg/cm2 100L/min |
Size | 2400×800×1300mm(L×W×H) |
Net Weight | 120Kg |
Terms and Conditions:
Payment: 30%TT in advance, 70%TT before machine ship out;
Delivery time: around 35 days to leave our factory after advance payment and samples
Warranty: one year after shipment.
Packing: according to export standard
See following some photos :
Welcome to email us to know more advantages of our machine. We will send you videos and detailed photos together, which will surprise you !!
