Home > Products > semi trailer Axle > Truck Steel Semi Trailer Axle Beam
Truck Steel Semi Trailer Axle Beam
- QingDao
- T/T Credit Card
You May Like
-
China Semi-trailer Axle Square Beam for Sale
-
Hot Selling High Quality Semi Trailer Axle With Square Beam
-
Hot Sale American Type Axle Tube for Trailer
-
American Type Semi Trailer Axle Outboard Drum Series
-
Hot Selling and Used Semi Trailers Germany Bpw Axle
-
Semi Trailer Axle/ German Bpw Type Axle With Good Quality
Product Details
| Parts | Trailer Axles | Max Payload | 20T | |
| Size | 150*150 | Place of Origin | Shandong, China | |
| Brand Name | KETIAN | Model Number | KTG/KTA |
Product Description
Truck steel semi trailer Axle Beam
Product Description
1) Type: American/FUWA, German/BPW type Axle
2) Drum Axle, Rear Axle
3) Track can be made according to customers' request
4) Certificate: ISO/TS16949
Every parts Material
1.Axle beam material:20Mn2
2.Brake drum:QT450
3.Hub:HT250
4.BRAKE CHAMBER:Q235
5.AXLE HEAD:20MN2
6.SELF-LOCKING NUT:40Cr
7.SELF-LOCKING BOLT:35m10x15
8.WASHER:35CrMn
9.AXLE BOLT:35CrMn
10.BEARING LANDING PLATE:Q235
Packaging & Shipping
1.Covered the brake drum with the plastic film & Tighten
2.Every 2 or 3 axles are connected with each other with link, avoid axles rolling in containers
3.Generally, axles without packing; While it needs packing if in bulk
4.Put all the ordered axles in containers
Or according to customers' requests
Germany style axle beam specification
Model | Rated Load | Total Length | Track | Axle Tube | P.C.D | H | Studs |
KTG-12T | 12000 | 2144 | 1840 | 150*150*12 | Φ335 | Φ281 | 10-M22 |
KTG-14T | 14000 | 2198 | 1840 | 150*150*14 | Φ335 | Φ281 |
|
KYG-16T | 16000 | 2272 | 1850 | 150*150*16 | Φ335 | Φ281 |
American style axle beam specification
Model | Rated Load | Total Length(mm) | Track | Axle Tube | P.C.D | H | Spring |
KTA-10.5T
| 10500 | 2165 | 1820 | Φ127 | Φ335 | Φ281 | ≥950 |
KTA-13T
| 13000 | 2185 | 1840 | Φ127 | Φ335 | Φ281 | ≥930 |
KTA-13T
| 13000 | 2185 | 1840 | 150*150 | Φ335 | Φ281 | ≥930 |
KTA-14T
| 14000 | 2185 | 1840 | 150*150 | Φ335 | Φ281 | ≥930 |
KTA-16T
| 16000 | 2205 | 1850 | 150*150 | Φ335 | Φ281 | ≥940 |
KTA-20T
| 20000 | 2252 | 1850 | 150*150 | Φ335 | Φ281 | ≥940 |
Jinan Ketian Auto Parts Co.,Ltd. is a professional manufacturer of semi trailer and semi
trailer parts (axle, suspension, fifth wheel, landing gear, kingpin,twist lock)...
located In Liangshan county Shanong Province China where is a main and
professional production base of semi trailer in china even in the world!
Truck steel semi trailer Axle Beam
Our main products
Our show
Our certificate
Welcome to patronize!
