prefab tavern assembly prefabricated house kit house

FOB Price

US$ 65 - 85 / Unit

1 Unit(Min. Order)

Port XINGANG(TIANJIN)
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Beijing, China	Brand Name	CDPH
Model Number	ZA type	Material	Steel
Use	Hotel, House, Office, Shop, Toilet, Other, Hotel, House, Office, Shop, Toilet, Workshop,Plant

Product Description

Prefab house A type is a flexible modular house. The size and layout can be designed as per customers’ requirements and local climate. When delivery, it is knock-down to save space. Based on bolts connection without welding work, it could be assembled and disassembled easily and six common workers can finish 50m2 in 8 hours according to instruction and CD.

The detail information is as follow:

Name	Item	Specification
Dimension	Length	No limited
	Width	Not more than 12.79 m
	Slope of the roof	01:05
	Storey	Single storey
	Height	Standard 3-4m
Standard	Wallboard	75mm thickness color steel sandwich panel, color: white.
	Roofboard	75mm thickness color steel sandwich panel, color: while, blue or red.
	Door	SIP door
	Window	PVC sliding window
	Main structure	Hot Galvanized,C170: Q345,C120 : Q235
	Connection parts	Galvanized, Q195-Q235
	Foundation	Concrete Strip foundation or flat slab
	Flashing parts	Color steel sheet, 0.4mm
Option	Door	Security door; Aluminum alloy door; color steel door
	Window	Aluminum alloy window
	Ceiling	Mineral wool soundless panel or Calcium silicate board
	Flooring	Ceramic tile, PVC flooring, composite wooden floor
	Electric system	It can be designed and provided
	Water system	It can be designed and provided
	Compressure parts	Aluminum alloy corrugated parts
	Other accessories	Sanitary ware, kitchen wares, furniture, etc
Resistance	Roof live Load	0.45KN/sqm (Can design according to local weather condition)
	Wind proof	10-11 grade (Can design according to local weather condition)
	Aseismatic intensity	7 degree

Name	Item	Specification
Dimension	Length	No limited
	Width	Not more than 12.79 m
	Slope of the roof	01:05
	Storey	Single storey
	Height	Standard 3-4m
Standard	Wallboard	75mm thickness color steel sandwich panel, color: white.
	Roofboard	75mm thickness color steel sandwich panel, color: while, blue or red.
	Door	SIP door
	Window	PVC sliding window
	Main structure	Hot Galvanized,C170: Q345,C120 : Q235
	Connection parts	Galvanized, Q195-Q235
	Foundation	Concrete Strip foundation or flat slab
	Flashing parts	Color steel sheet, 0.4mm
Option	Door	Security door; Aluminum alloy door; color steel door
	Window	Aluminum alloy window
	Ceiling	Mineral wool soundless panel or Calcium silicate board
	Flooring	Ceramic tile, PVC flooring, composite wooden floor
	Electric system	It can be designed and provided
	Water system	It can be designed and provided
	Compressure parts	Aluminum alloy corrugated parts
	Other accessories	Sanitary ware, kitchen wares, furniture, etc
Resistance	Roof live Load	0.45KN/sqm (Can design according to local weather condition)
	Wind proof	10-11 grade (Can design according to local weather condition)
	Aseismatic intensity	7 degree
