3.5inch J1900 fanless 2 LAN LVDS industrial embedded motherboard

FOB Price

USD $1 - $100 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Type	Embedded Industrial Motherboard
Brand Name	hcsmart	Model Number	EC3J1900-6CDP2L
Place of Origin	Guangdong, China

3.5inch fanless J1900 LVDS industrial embedded motherboard

Product Description

Processor	CPU	Intel Baytrail J1900
	Frequency	Quad core 2.0 up to 2.41g
	Chipset	NA
	TDP	10w
Memory	Slot	1*SO-DIMM DDR3 Memory up to 8g
Memory	capacity	MAX to 8gb
Storage	Connector	1*SATA3.0
		1*MSATA
		1*MINI PCIE (For WIFI/3G)
Display	Chipset	integrated Intel HD graphics
Display	connector	HDMI,VGA header eDP
LAN	chipset	2*Realtek 8111E 1000M
LAN	Connector	2*RJ45
Audio	chipset	1*Realtek ALC662 HD
Audio	connector	1*Line-out
I/O	COM	6*COM header
	LPT
	USB	2USB 3.0 8USB2.0(4*USB2.0 need to be expanded )
	GPIO
	Header	4F-USB2.0 6COM-SET 1PIN DCD/SV for options 5COM header RS232 1COM header RS232/RS485 1EDP 1F_PANEL 1CLR-COMS jumper 1SYS-FAN 1SATA-PWR 1SPEAKER 1J485
Power	powr supply	1DC IN 12V/5A 14PIN ATX
OS	version	Win7/Win8/XP/Linux
BIOS		AMI BIOS
working environment	working temp	-10~60℃
	storage temp	-10~70℃
	relative humidty	5%-95% non-condensing
Form factor	size	3.5inch 148X102MM

Packaging & Shipping

Carton box packaging, shipped by door to door express (Fedex, Dhl,Ups,Tnt etc,) or air

Our Services

We can give you 1 year warranty and 1% RMA,

To assure the quality, we usually do full test befor shippment to avoid the quality issue

24*7 hotline for inquiry, if you have any questions about our products, you can contact us any time.
