Pressure Water Level Transducer KDMC20A
- China any port
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | KAIDI | |
| Model Number | KDMC20A |
Each one in well protective inner carton, 10 pcs one box
Product Description
Pressure water level transducer KDMC20A
Specification:
Medium | Gas, liquid, oil (compatible with SS316) |
Measuring range | Gauge pressure(G)---Max(0 ~ 60)MPa, Min(0 ~ 0.5)KPa |
Absolute Pressure(A)---Max(0 ~ 40)MPa, min (0 ~ 5)KPa | |
Negative pressure(B)--- Max (-0.1 ~ 40)MPa, Min(-0.2 ~ 0.2 )KPa | |
Accuracy | 0.1, 0.25, 0.5 |
Overload capability | 2-3 times of Measuring range |
Long-term stability | <0.2%FS/yr, <0.5%FS/yr |
Power supply | 15 ~ 36 VDC(rated 24VDC) |
Output | (4 ~ 20)mA (2/3/4 line), (0 ~ 10/20)mA, (0 ~ 5)V, (1 ~ 5)V, (0 ~ 10)V |
Display | LCD or pointer gauge |
Calibration | Potentiometer |
Working temperature | -40 ~ 80°C Temperature Compensation: -20 ~ 70 °C |
Process connection | M20×1.5 (ID Φ5) or customized |
Weather proof | IP65 |
Optional radiator | Up to 300°C |
Isolation diaphragm | SUS 316 |
Sensor Connection material | 1Cr18Ni9Ti |
Shell material | Aluminum alloy |
