Wool Rock Sandwich Panels

Who Are We ?

Thank you for your interest in Henan CangLong Steel Structures co,.ltd ,  We are a family owned business and have been in operation since 2007, specializing in post frame steel buildings. Our individually engineered permanent structures are the best choice for customers requiring speed of construction and economy coupled with aesthetic value. Our buildings are ideal for residential, commercial , agricultural ,industrial and chemical factories ,warehouses & stores , hospitals & clinics,multi-storey buildings , supermarkets ..

Why is CangLong Steel Structures the Right Choice?

Your investment is an important decision and should be realized through a financially stable company.  Our deep community roots and stout economic strength gives us an exceptional advantage in hiring experienced professionals who will complete your project to your expectations.

Introduction

Light steel movable house is a kind of light steel skeleton, with sandwich panel as enclosure material, spatial association with the standard module series, bolts used to connect components, a new concept of environmental protection activities in economic housing. Activities of the housing can be conveniently assembled and disassembled, realizes general standard for temporary buildings, set up environmental protection and energy saving, fast and efficient architectural concept, make the temporary housing into a series of development, integrated production, matching of supply, inventory and multiple turnover use styling products field. The performance and quality of light steel housing:

1, the real seismic activity has seven level, twelve level wind;

2, two floor activity room design can support the dynamic loading of 150kg/ square meters, suspicious point console;

3, the real life in ten years

Materials needed

1, external wall plate adopts the double hot dip galvanizing paint pressure type color steel plate combination, middle using EPS (foam) with high strength glue automatic machinery production and become, or polyurethane, rockwool sandwich panel. Specifications; 5500mm*1200mm*75mm.

2, partition board, using double hot dip galvanizing paint pressure type color steel plate combination, middle using EPS (foam) with high strength glue automatic machinery production and or polyurethane, rockwool sandwich panel. Specifications; 2640mm~2750mm*1200mm*50mm.

3, the roof panel, using double hot dip galvanizing paint pressure type color steel plate combination, middle using EPS (foam) with high strength glue automatic machinery production and become, or polyurethane, rockwool sandwich panel. Specifications; 7400mm*1200mm*100mm.

4.25*25 wood with a wire connecting parallel ,plastic buckle plate, a self tapping screw fixed wood buckle, plastic buckle plate specifications for 3600mm*200mm.

5.Supplementary material ,the activities of the housing; the I-shaped aluminum, color coated steel door frame, window frame profiles, special, waterproof glue, hardware accessories, different places with different materials. Door: plastic steel door 2100mm*800mm. Window of model steel window 1200*1200.

Henan Canglong steel structure company is one group in the collection of development, design, steel structure fabrication and installation, testing  . The company has steel structure engineering contractor level which is issued by the Ministry of construction and also  steel structure of China Steel Structure Association awarded the manufacturing enterprise member. Our company scope of business throughout  Southern China, southwest, North China, central China and other regions of Hong Kong and Macao, Southeast Asia, the Middle East, radiation, North America and other countries or regions, The product structure buildings include energy, traffic, covering building ships, nuclear power, wind power and other fields of steel structure residence.

Fixed packing, loading, transportation, unloading the matters needing attention:

(1) the lifting large there must be a person responsible for the use of fixture, suitable, strictly abide by the rules of lifting, to prevent the occurrence of vibration, impact, deformation or damage, fall in the hoisting process.

(2) at the time of loading, there must be a special supervision, check car number and packing, the car pile up securely, and to increase the necessary binding component loosening, prevent the loss.

(3) remained stable in the transport process, the vehicle at the time of shipment, on the long, wide, high object transport, must be trained pilots, escort personnel responsible for, and mark is arranged on a vehicle.

(4) no rough handling, loading and unloading personnel handling, weight, size should be familiar with the components, and check the horse sling, rigging, prevent accidents.

(5) the member to the construction site, timely organization of unloading, stacking area.

(6) the crawler crane carrying member, should pay attention to the surrounding terrain, air condition, prevent the crawler crane overturning and component collision.

The Edge

 Competitive Prices Our production capacity (approximately 20000 metric tons annually) together with effective and economic

 engineering and manufacturing methods enable us to offer the most competitive prices in the industry.

Fast Quotations

 Quotations for simple buildings can be submitted quickly due to vast experience of our staff and the advanced software we use.

Fast Delivery

  We are able to design, detail, fabricate and supply simple buildings in approximately 4 weeks.
 Most of our buildings are delivered and erected within 8 weeks (this relies on various factors such as stock position, weather etc).
Site Supervision

  A site supervisor is always present at site to ensure that work is being carried out satisfactorily.
  Any problems that arise are quickly dealt with to minimise any delays.
  Safety on site is also made a priority.

Our company with factory is located in Zhengzhou city , Henan province . Sincerely invite you to visit our company ,you will be clear to our products qulity  control of production process ! Welcome you to place order with our company !!
