Hydraulic Punching Die
- Ningbo/Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | iwiss | |
| Model Number | Type B | Type | Other, Hydraulic tool |
Product Description
Specifications
Mild steel up through 3.5mm(10gauge); Punch mild steel,aluminium,fiberglass and plastic.Capacity: Mild steel up through 3.5mm(10gauge)
Application: Punch mild steel,aluminium,fiberglass and plastic.
Operation:Battery,hydraulic,ratchet or manual drivers.When used with ratcher , hydraulic or battery drivers, buy the punch and die only ; the draw stud is part of the driver kit.
CONDUIT&PIPESIZE HOLESIZE(ACTUAL) CAPACITY DRAWSTUD WITHBEAING | ||||||
| diameter (INCH) | diameter mm | mm | GA |
| |
1/2” | 7/8 | 0.885 | 22.5 | 3.5 | 10 | 3/8”,24UN |
3/4” | - | 1.115 | 28.3 | 3.5 | 10 | 3/4”,16UN |
1” | - | 1.362 | 34.6 | 3.5 | 10 | 3/4”,16UN |
1-1/4” | - | 1.701 | 43.2 | 3.5 | 10 | 3/4”,16UN |
1-1/2” | 1-15/16 | 1.951 | 49.6 | 3.5 | 10 | 3/4”,16UN |
2” | 2-3/8 | 2.416 | 61.5 | 3.5 | 10 | 3/4”,16UN |
2-1/2” | 2-7/8 | 2.914 | 74.0 | 3.5 | 10 | 3/4”,16UN |
3” | 3-1/2 | 3.539 | 89.9 | 3.5 | 10 | 3/4”,16UN |
3-1/2” | 4 | 4.044 | 102.7 | 3.5 | 10 | 3/4”,16UN |
4” | 4-1/2 | 4.544 | 115.4 | 3.5 | 10 | 3/4”,16UN |
5” | 5-5/8 | 5.675 | 144.1 | 3.5 | 10 | 3/4”,16UN |
6” | 6-3/8 | 6.375 | 161.9 | 3.5 | 10 | 3/4”,16UN |
Round Manual Knockout Punch Kits :
DESCRIPTION CAPACITY(MILD STEEL) | ||
| mm | GA |
1/2”-11-4”Conduit Size
| 3.5 | 10 |
11/2”-2”Conduit Size
| 3.5 | 10 |
Type B 1 /2”-11/4” Knockout Punch Kit lncludes
DESCRIPTION HOLE SIZE(ACTUAL) | ||
| diameter(INCH) | Diameter(mm) |
1/2”Conduit Size Punch&Die | 7/8” | 22.50 |
3/4”Conduit Size Punch&Die | 1.115 | 28.30 |
1 Conduit Size Punch&Die | 1.362 | 34.60 |
1-1/4Conduit Size Punch&Die | 1.701 | 43.20 |
3/8”,24 UN Draw stud with beaing | ||
3/4”,16 UN Draw stud with beaing | ||
Plastic box | ||
Type B 1 1 /2”-2” Knockout Punch Kit lncludes:
DESCRIPTION HOLE SIZE (ACTUAL) | ||
| diameter(INCH) | Diameter(mm) |
1-1/2”Conduit Size Punch&Die | 1-15/16 | 49.6 |
2” Conduit Size Punch&Die | 2-3/8 | 61.5 |
| ||
Plastic box | ||
