Hige Speed HDPE Film Blowing Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Film
Plastic Processed	PE	Blow Moulding Type	Extrusion Blow Moulding
Automatic	Yes	Place of Origin	Fujian, China
Brand Name	donghailong	Model Number	SJ45-FMS650H,SJ55-FMS850H.SJ65-FMS1300H
Certification	CE,SGS	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

High Speed HDPE Film Blowing Machine
with auto winder/great output
compact design
its products are for packing
shopping bags

Hige Speed High-density Polyethylene/HDPE Film Blowing Machine

	Model	SJ45-FMS850H	SJ55-FMS1100H	SJ65-FMS1300H
	Max. Folded Film Width	700mm	1000mm	1200mm
	Film Thickness	0.008~0.15mm	0.008~0.15mm	0.015~0.20mm
	Output	45 kg/h	60 kg/h	80 kg/h
	Raw Material	HDPE
	Screw Diameter	Φ45mm	Φ55mm	Φ65mm
	Screw L/D	28:1	28:1	28:1
	Power of Main Motor	15KW	22 KW	30KW
	Die Diameter	HDPEΦ60mmΦ80mm	HDPEΦ80mmΦ100mm	HDPEΦ100mmΦ120mm
	Die Heater Capacity	3.45KW	3.45 KW	6.1 KW
	Cooling Air Blower	2.2KW	3.0KW	4.0 KW
	Haul-off Driving Motor	1.5 KW	1.5KW	1.5 KW
	Take-up Speed	10~100m/min	10~100m/min	10~100m/min
	Winder Drive Motor	2.2KW	2.2 KW	2.2 KW
	Temperature Control	6 units	6 units	6 units
	Total Power of the Machine	~32KW	~43 KW	~55KW
	Shape Size( L x W x H)	4.5X2.5 X 4.0m	5.5 X 3.0X4.5m	6.3 X3.5 X 5.5m
	Weight	~2000kg	~3000kg	~3800kg
,. Correct specifications depend on the actual model all specifications are subject to change without prior notice.
