Home > Products > H3.1-1KW Wind Turbine > Special design 1KW-5KW DC48V Wind Energy Systems for telecom solutions

Special design 1KW-5KW DC48V Wind Energy Systems for telecom solutions

FOB Price

USD $1,500 - $1,800 / Set

10 Sets(Min.Order)

Port Shanghai
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Anhui, China		Brand Name	Hummer
Model Number	H3.1-1000W		Type	Other, Wind Energy Systems

Product Description

Specifications

1KW-5KW DC48V Wind Energy Systems
1.CE proved+7 patents
2.lighter,smaller,higher than tradition
3.SKF bearings
4.Factory

Special design 1KW-5KW DC48V Wind Energy Systems for telecom solutions

Hummer offers various capacities of wind energy systems as well as charge voltages and frequency to meet different clients' requests from every corner of the world. We developed charge voltage DC48V system for 1kw; 2kw; 3kw; 5kw models by changing the diameter and structure of generator enameled wire. The 48V systems are specifically for the solution of telecom with DC48V loads and provide customers with a better choice to lower the cost.

Put 1KW DC48V Wind Energy Turbine As Example:

H3.1-1KW Specifacations
Configuration	3 Blades, Horizontal axis, upwind
Rotor Diameter	3.1m
Swept Area	7.55 m²
Direction of Rotation	Clockwise looking upwind
Rated Power	1 kW at 10m/s
Maximum Output Power	1.2 kW at 20m/s
Battery Bank Voltage	60 Vdc
System Output Voltage	110/220 Vac
Cut-in Wind Speed	3 m/s
Rated Rotating Rate	500 r/min
Working Wind Speed	3-25 m/s
Survival Wind Speed	50 m/s
Generator Efficiency	>0.80
Wind Energy Utilizing Ratio	0.45 Cp
Alternator	Permanent magnet alternator, SCF technology
Alternator Weight (kg)	15 kg
Gearbox	None, Direct drive, generator prepositive design
Blade Material	Fiberglass reinforced composite
Over Speed Regulation	Passive furling tail design
Shutting Down Method	Manual & Automatic electromagnetism Braking
Warranty	2 years for generator and 1 year for other parts

The electricity from wind generator charges the batteries after being rectified and powers the telecommunication equipment.

Model: H3.1-1000W

Features:

1. SCF Supercritical generator

Hummer’s 1KW wind generator adopts SCF supercritical technology which won a gold award in the 37th Salon Eureka in Brussels. This technology significantly reduces generator’s weight and size down to 25% to 30% of the traditional one, and the production efficiency is 25% to 30% higher. This ensures that the generator functions perfectly in small wind condition.

2. SKF bearings

Hummer 1KW wind turbine adopts two SKF (Svenska Kullager Fabriken) bearings which are produced by the largest bearing manufacturer in the world, with the perfect internal geometric structure, known for its life-time endurance and reliable quality. Ordinary bearings need to be changed every two or three years, while SKF bearings can greatly reduce the maintenance costs on this matter.

3. Low noise

The design of the rotor blade of Hummer 1KW wind turbine absorbs the highlights of the small aircraft’s airfoil, which is compliance with the aerodynamic standards. It provides a more aesthetic look and a higher efficiency and reduces the noise production as much as possible.

4. Double braking protection

Hummer 1000W wind turbine adopts the double braking protection system, which are the yawing mechanism and the electromagnetic braking system to regulate the rotation of the wind turbine. It is safe and convenient to shut down the whole system both manually and automatically.

Currently Hummer offer wide range:

500W-100kw wind turbine Off-grid /Grid-tied;

400W-600W Wind-Solar LED street light and traffic light;

Wind-Solar hybrid generating system;

Wind-Solar-Diesel hybrid generating system;

1KW-5KW DC48V Wind Energy Systems for telecom.
