Automatic Pipe Manipulator / Rotating Movable Weld Manipulator
- 20 Set / Sets per Month
- Shanghai Port
- T/T
You May Like
-
Column And Boom Weld Manipulator / Pinch Welding Rotator
-
Column And Boom Weld Manipulator OR Pinch Welding Rotator
-
Combined type automatic pipe welding positioner
-
Combined Welding Positioner and Automatic Welding Positioner
-
FSM-50T & FSM-100T Combined welding turntable, welding rotary tables
-
China high quality Pipe Welding Positioner with 3-jaw chuck
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Certification | CE, ISO |
Product Description
1. Main features
a. Manipulator control system using digital control, easy operation, precise control, and other equipment to facilitate linkage control
b. According to customer requirements, it can be installed electrical extension unit inside telescopic arm operator's seat and safeguard ladders, but also supporting a variety of tracking and monitoring, arc oscillation, transmission devices of flux recovery.
c. Welding manipulator is divided into small, medium, heavy types
2. Main functions
There are a number of the manipulators, such as the stationary type, the stationary and rotating type, and the all orientation type. The movement of the boom is adopted with frequency conversion control, and also you can select PLC programming controller, which is good in mechanic precise, is accurate in positioning, and we are sure the company is able to design and manufacture special manipulators for our customers.
3. Main parameters
Type | Heavy-duty | Middle-duty | Light-duty | Precise | |||
Model | 8x6 | 5x6 | 4x5 | 3.5x5 | 3x4 | 2x2 | 3x4 |
Boom up and down stroke (mm) | 8000 | 5000 | 4000 | 3500 | 3000 | 2000 | 3000 |
Effective stroke of boom (mm) | 6000 | 6000 | 5000 | 5000 | 4000 | 2000 | 4000 |
The suitable diameter of cylinder (m) | 1-8 | 1-5 | 1-4 | 0.7-3.5 | 0.7-3 | 0.5-2 | 0.7-3 |
Rotating of the base frame | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° | ±180° |
Up and down speed of boom (m/min) | 0.9 | 1 | 1 | 1 | 1 | 0.3 | 1 |
Expansion speed of boom (m/min) | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 | 0.12-1.2 |
Froward backward speed of the trolley (m/min) | 3 | 3 | 3 | 3 | 3 | 1.5 | 3 |
The center distance of the trolley track (mm) | 2308 | 1780 | 1780 | 1780 | 1500 | 900 | 1500 |
