Stationary Pipe Welding Manipulator Rotary Welding Column And Boom

1. Description

        Welding manipulator series is composed of auto welding mechanical equipment. It can use with welding rotator, widely applied to industries such as boiler, pressure vessel, petroleum, chemical industry and mechanism.the characters of machine and main dimension is designed according to auto welding process,its just the right equipment to improve welding quality and realize welding automation.


2. Feature

a. Auxiliary equipment for welding center.
b. Automatic welding manipulator can be adopted with various welding power (Chinese or international famous brand).
c. Stretching of cross boom adapts AC frequency converter step-less speed control and run with steady speed.
d. Head equipped with electric cross slides, can adjust position of welding.
e. Chain break-resistant and anti-slip device in boom to guarantee safety.
f. Braking device can ensure column work in safe environment.
g. Customized manipulator requirements are accepted.
h. Automatic flux feeding, recovering devices, wire feeder device, working platform and  chair (Optional).


3.Main parameter

Welding Oscillate for Column and boom manipulator

a. Model: KB-L Straight welding oscillate
b. Power: AC220-250V, 50HZ, Single phase
c. Controller size: 120*175 *75 (W *L* H)
d. Weight: 2.9Kg
e. Speed: 0 - 2300mm/min
f. Centering movement: ±5mm
g. Swing range: ±15mm
h. Left-right stop: 0-2s
