Home > Products > Accessory Machine and Parts > Ovalizer Spiral Duct Roll Forming Machine 3100 Ovalizer Tubesformer
Ovalizer Spiral Duct Roll Forming Machine 3100 Ovalizer Tubesformer
- SHANGHAI/NINGBO/QINGDAO /TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
6 Meters Length ,Hydraulic drive, CNC ,Automatic Floder And Slitter Machine
-
CNC Metal Folder or Bending Machine,0.8-2mm thickness
-
CNC Aluminum Sheet Folding / Bending Machine Folding, Siemens PLC 0.8-2mm thickness
-
CNC operate Metal Fold ,Steel Bend and Automatic Slitter Machine,0.8-2mm thickness
-
Simple Steel / Metal Slitting Machine For Slitting 0.2-1.8x1300 Coil Into 10 Strips
-
Steel Flattening, cut to length and Slitting Machine
Product Details
| Condition | New | Type | Pipe Production Line | |
| Pipe Material | Stainless Steel | Application | Other, air | |
| Production Capacity | 100% | Place of Origin | Jiangsu, China | |
| Brand Name | FSM | Model Number | SV3100 | |
| Voltage | 380v | Power(W) | 18.5kw | |
| Dimension(L*W*H) | 5630*1250*1130mm | Weight | 2720kgs | |
| Warranty | 12month | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Spiral Tube Forming Machine/Former
Spiral Tube Former For The Pipe Industry
A continuous tube T is Spiral Tubeformer by spirally winding an extruded thermoplastic ribbon R
having mating edges which are joined together to form a spiral seam and having at least one reinforcing rib 3 which, when in its spiral wrapped form, projects radially out from the tube. At predetermined lengths, the tube is cut and at the same time the outer surfaces of the tube on each side of the cut are shaped to facilitate handling and interconnecting of pipe section 1 thus formed. At least one end of the pipe has an annular groove 6 at a uniform distance from that end. This groove is formed by cutting a path through each of the radially extending reinforcing ribs intersecting its annular path. An elastomeric O-ring 8 engages the outer surface of the pipe
and the axial movement of the Oring is restrained by the walls of the groove formed by the radially extending
reinforcing ribs.An apparatus 30 for cutting the tube at predetermined lengths into pipe sections while the tub is proceeding out of the spirally-winding operation also imparts to the outer surfaces the desired shape as well
as cuts the groove for the elastomeric O-ring. This apparatus performs this cutting and shaping operation
without interrupting the continuous forming of the tube from the spirally-wound thermoplastic ribbon.
"Seamless" steel pipes are those whose manufacture does not involve welding of any kind. The process starts with a long, solid cylinder of steel known as a "billet." The billet is loaded into a special machine that uses electrical resistance to heat the billet to a malleable temperature. A pair of rollers with perpendicular axes (Figure 1) rotate the heated billet rapidly around its own axis while slowly drawing it into special instrument known as a "piercer." The piercer slowly enters the rotating billet as a near perfect Tube forming around it. To better illustrate, think of the process like a potter's wheel; when you put your finger into the top of the spinning clay, a perfectly-symmetrical hole forms around the digit. Formally, this phenomenon is known as the "Mannesmann Effect."
Technical Data
Diameter Range | Φ100-1500mm |
Thickness of Strip | Galvanized steel 0.4-2.0mm Stainless steel 0.4-1.2mm |
Width of Strip | Standard 137mm |
Strip Speed | 1-30m/min |
Lockseam | Outside tube ,on the inside request |
Motor Power | Mainframe:16.5kw |
Voltage | 380V/60Hz |
Cutting System | Plasma Cutter,Saw Blade Cutting |
Weight | 2300kg |
Dimension | 3800mm×2160mm×2720mm |
The external of machine:
Machine configuration type
(1)Bare machine,no others
(2)Standard Configuration (6M Manual out table)
(3)Required Configuration (6M Automatic tilt rack)
(4)9M/12/ out table,or others requirements,pls contact sales
