ZLP100,500,630,800 Powered Suspended Platform

Friendship Machinery "ZLP500" Temporary Suspended Platforms to Customers Specification. Many Optional Capacities, Platform Size, Controls and Height Of Lift

        ZLP500 platform is for temporary applications for lifting people and their working equipment - at unlimited heights.

        The model perfectly suited to lightweight applications such as painting and decorating, refurbishing, jointing and repairs, windows cleaning etc.

        The complete system consists of the working platform equipped with two electric LTD hoists and the support wheels, suspended by means of steel wire ropes from a suspension structure.

1. The main para. Of ZLP500 suspended platform:
- Rated Load: 500kg
- Lifting Speed: 9.3m/min
- Voltage-3Phase: 380V (415V/ 220V)
- Frequency: 50HZ/ 60HZ
- Power: 1.1kw * 2
- Hoist: LTD50
- Safety Lock: LSF308
- Diameter of Wire Rope: 4*31SW+FC-8.3mm
- Platform Size: (2.5 * 2) * 0.76 * 1.45m
- Weight of Suspension Jibs: 340kg
- Weight of Lifting Part: Aluminum290kg/ Steel 410kg
- Counter Weight: 800kg
- 20’ GP Qty of Package: 12

2. Platform Suspension

        The different variants are to be distinguished by their suspension principles. Three different stirrups allow to choose the platform the best to your requirements (type of work, type of building, maximum loads, number of persons).

- End stirrup:
Fitted at the ends of the platform.
Advantages:
The most economical and lightweight version, although showing extraordinary performances.

- L stirrup:
Placed at the rear of the platform behind the workers.
Advantages:
The working surface is completely clear and the whole façade can be easily accessed.

- Double-Deck Platform
