Product Details
| Place of Origin | Zhejiang, China | Brand Name | kangli or oem | |
| Model Number | rg6, rg6 cable | |||
| Number of Conductors | 1 |
Product Description
Specifications:
Construction
| Item | Material | Diameter(mm) | Remark |
| Inner conductor | BC/CCA/CCS/TC | 1.02 | |
| Dielectric | Foam PE | 4.6 | |
| First Shield | Aluminum Foil/Bond AL Foil | 4.75 | |
| Second Shield | Al/BC/TC/CCA Braid | 5.35 | 30%-90% |
| Jacket | PVC/PE | 6.93 |
Electrical Characteristics
Sparker Test: | 4000VAC |
Impedance: | 75+3 Ohm |
Capacitance: | 54+3pF/m |
Velocity of Propagation: | 85% |
Return Loss: | 20dB min (5-2300MHz) |
Attenuation
Attenuation | [@68o F. (20o C.)] | |
Frequency (MHz) | Maximum (dB/100 ft.) | Maximum (dB/100 m) |
5 | 0.58 | 1.9 |
50 | 1.5 | 4.9 |
100 | 2.0 | 6.5 |
200 | 2.8 | 9.2 |
400 | 4.1 | 13.6 |
700 | 5.6 | 18.4 |
900 | 6.2 | 20.3 |
1000 | 6.5 | 21.4 |
1450 | 8.0 | 26.2 |
1800 | 8.5 | 27.9 |
2100 | 9.5 | 31.1 |
2250 | 10.0 | 34.0 |
3000 | 11.4 | 37.5 |
Factory Show:
Certification:
Packing and Shipping:
Team show:
FAQ:
♦What kind of cable do you produce?
•We specialize in producing coaxial cable, lan cable, telephone cable, speaker cable, alarm cable ,etc.
♦What is your MOQ?
• Normally, the MOQ is 10km.
♦What is your delivery time?
• Normally, our delivery time is 15 days after received deposit. It is base on the quantity of the order.
♦What is your payment term?
• Normally, we accept T/T. Other payment, we can negotiate with customers.
♦What is your quality?
• We have special quality control department to ensure our good quality
♦Can your factory customize cables basing on customer's sample?
• Yes, we can. OEM/ODM is available.
♦ I can't find what I want. Can you help me?
• Yes. Please contact us, we will do our best to help you.
