cat5e utp lan cable
- Ningbo/Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | OEM | |
| Model Number | LK-CAT.5e-UTP | Type | Cat 5e | |
| Number of Conductors | 4 |
Product Description
Specifications
-Quality Approved-Competitive price
-Promote Delivery time
CAT.5e UTP LAN CABLE
Description:
Related temperature: 60°C, 75 °C
Solid bare copper conductor
Color-coded PE insulation
Rip cord (optional)
Lead free PVC jacket
Reelex package available
Industrial Standard:
UL444
ISO/IEC 11801
TIA/EIA 568B
Application:
Telephone Voice Wiring
10 Base-T
100 Base-T4
Token Ring
100VG-Any Lan
Electrical Characteristics:
Frequency (Mhz) | Atteuation (dB/100m) | NEXT (dB) | PSNET (dB) | ELFEXT (dB/100m) | PSELFEXT (dB/100m) | Return Loss (dB) | Impedance (ohm) |
| 1 | 2 | 65.3 | 62.3 | 63.8 | 60.8 | 20 | 100±15 |
| 4 | 4.1 | 56.3 | 53.3 | 51.7 | 48.7 | 23 | 100±15 |
| 8 | 5.6 | 51.8 | 48.8 | 45.7 | 42.7 | 24.5 | 100±15 |
| 10 | 6.5 | 50.3 | 47.3 | 43.8 | 40.8 | 25 | 100±15 |
| 16 | 8.2 | 47.3 | 44.3 | 39.7 | 36.7 | 25 | 100±15 |
| 20 | 9.3 | 45.8 | 42.8 | 37.8 | 34.8 | 25 | 100±15 |
| 25 | 10.4 | 44.3 | 41.3 | 35.8 | 32.8 | 24.3 | 100±15 |
| 31.25 | 11.7 | 42.9 | 39.9 | 33.9 | 30.9 | 23.6 | 100±15 |
| 62.5 | 17 | 38.4 | 35.4 | 27.8 | 24.8 | 21.5 | 100±15 |
| 100 | 22 | 35.3 | 32.3 | 23.8 | 20.6 | 20.1 | 100±15 |
Certification:
Factory Show:
