China Manufacture FESTO DNC Pneumatic Cylinder
- Ningbo or Shanghai
- T/T
You May Like
-
ISO15552 Standard Festo Pneumatic Cylinder Festo Type DNC Series Pneumatic Cylinder Made in China
-
SDA Series Compact Pneumatic Air Cylinder HOT SAIL
-
Pneumatic Thin Cylinder (SDA Series)
-
Pneumatic Compact Thin Air Cylinder (SDA Series)
-
Pneumatic Compact Air Cylinder (SDA Series)
-
Airtac Type SDA Series Compact Air Cylinder/Pneumatic Cylinder
Product Details
| Standard or Nonstandard | Standard | Structure | Piston Cylinder | |
| Power | Pneumatic | Body Material | Aluminum | |
| Maximum Stroke | 1200mm | Shaft Diameter | 32-100 | |
| Place of Origin | Zhejiang, China | Model Number | DNC | |
| Brand Name | Aiphonso |
Product Description
Ordering Code
| DNC | - | 63 | × | 50 | - | PPV | - | A | - | 30 | LB |
| Model | Bore | Stroke | Buffer | Magnet Code | Especially add length | S2:Double piston rod | |||||
| DNC:Basic type | Blank:Without buffer | A:With magnet inside | K2:Lengthen out screw | ||||||||
| HNC:Axiul foot base | PPV:With buffer | Blank:Standard type | K3:Front in screw thread | ||||||||
| FNC:Front rear flange | K5:Out standard screw thread | ||||||||||
| ZNCF:Front rear axie pin | K8:Lengthen piston rod | ||||||||||
| ZNCM:Middle axie pin | |||||||||||
| SNCB:Single-ear base | |||||||||||
| SNCL:Double-ear base | |||||||||||
Specification
| Bore(mm) | 32 | 40 | 50 | 63 | 80 | 100/125 |
| Action type | Double Action | |||||
| Working Medium | Filtered Air | |||||
| Pressure Range | 0.1~1.0MPa | |||||
| Temperature Range | 5~60℃ | |||||
| Speed Range | 50~500mm/s | |||||
| Buffer Type | Air Buffer(Standard) | |||||
| Buffer Stroke | 24 | 32 | ||||
| Joint Pipe Bore | 1/8" | 1/4" | 3/8" | 1/2" | ||
Fenghua Aiphonso Industrial Autaomation CO., LTD
is a professional manufacturer of pneumatic components,solenoid valves, cylinders,fittings and so on. It has more than 100 employees and covers an area of over 4,000 square meters.Technology-oriented, quality-based and continual quality improvement make it capable of passing ISO9001:2000 Quality System Certification .Our Products are well sold in Southeast Asia,the Middle East and other regions.
