LIYU Victor KJ-II series UV Flatbed Printer

Specifications

 LIYU Victor KJ series UV Flatbed Printer:

1.Printhead Characteristics: Adopt the advanced Japanese Konica UV specialized head, 1024 nozzels double staggered, built-in temperature control system, real printing resolution up to 1440dpi,printing speed double compared to the KM512MH.

2.Type of Media: glass, ceramic, aluminum, wood, doors, cardboard, Chevron board, ceiling, MDF, metal lacquer panels, toilet cover, acrylic, plexiglass, etc.

3.Mechanic Superiority: dual lead screw & dual linear guide broadside scanning mechanical structure, industry-leading machinery precision; Table loading capacity of 100kg/sqm, crossbeam up and down automatically, maximum media thickness up to 100mm; Sub-vacuum absorption table enables the printing on different sizes of media; Auto. detection of media, Auto. detection of Origin, pneumatic medium jack-up system plus rolling bearings enables even a single person can load the large-format media easily.

4.Electronic control Superiority: Independent developed entire control system, classic combination of USB and Three-Optical fiber far speed data transmission system, LIYU patent software control system, have experienced numerous customers trials.

5.Pressure & Ink supply control: Closed-loop automatic control, reliable printing quality; pneumatic control components imported from Japan, guaranteed quality; LIYU patent Valve cleaning system, easy to maintain.

6. Main tank ink level display function, brand new and user-friendly design of control panel, makes the human-computer communication more  intuitive, convenient and faster.

7. More Color options: The Machine can be configured as KCMY / KCMY + W + V / KCMY LC LM / KCMY LC LM + W + V; Moreover, the machine could achieve the bed and cover coating or spot-color printing.
