led display video processor, VMS626 LED VIDEO PROCESSOR, LED screen image processing for visual display

FOB Price

Negotiable / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	OEM
Model Number	VDWALL 603/603s	Usage	Other, Outdoor, Indoor, Semi-outdoor
Tube Chip Color	Other, Single color, dual color, full color	Display Function	Other, Supports video, animation, text, images, information etc
Pixels	Other, 5mm, 6mm, 7mm, 10mm, 16mm, 20mm etc	Screen Dimension	Customized size

1. SDI. HDSDI(1080i) Input.
2. HD Text, Flash, Graphics & Logo Overlay
3. Seamless Switching,Fade-in / Fade-out
4. CE, ROHS

Features

10+ Bit Faroudja® DCDI Cinema Processing
New Faroudja® Real Color®
Advanced 4x4 Pixels Interpolation Scaling Algorithm
HD Text, Flash, Graphics & Logo Overlay
Seamless Switching,Fade-in / Fade-out
Unrestricted HD Picture-in-Picture (PIP) & Picture-by-Picture
Independent H & V Scaling Ratios
HDMI 1.3a with HDCP, HD 1080p input
SDI. HDSDI(1080i) Input
1920 x 1080 p or 1600 x 1200 output for single machine
Multi-machine in parallel, 6 x 6 in parallel can connect 11520 x 6480 LED screen
Fast 64-level output brightness adjustment
Easy setup and adjustment through keys on the panel
Press keys on frontal panel to directly select 7-channel input signal source,
including: 1 x SDI/HDSDI 1 x HDMI(with HDCP) 1 x DVI
1 x VGA 1 x DP(DisplayPort) 2 x CVBS
2 channels can be configured to connect external stereo audio, plus DP, HDMI and SDI audio, there are 5-channel audio for synchronous switch
2 LED Transmission Cards Built-in ability (The processor does not include the Transmission card!)

Specifications

Inputs
Nums/Type	2×Composite video 1×D/P(Display Port) 1×VGA (RGBHV) 1×DVI 1×HDMI 1×SDI ( HDSDI )
Video system	PAL/NTSC
Composite Video Scope/Impedance	1V (p_p) / 75Ω
VGA Format	PC(VESA)	≤1600x1200 @60HZ
VGA Scope/Impedance	R,G,B = 0.7 V (p_p) / 75Ω
DVI Format	SD/HD(CEA-861)		≤1920x1080P @60HZ
	PC(VESA)		≤1600x1200 @60HZ
HDMI Format ( HDCP )	SD/HD(CEA-861)		≤1920x1080P @60HZ
	PC(VESA)		≤1600x1200 @60HZ
DP Format	SD/HD(CEA-861)		≤1920x1080P @60HZ
	PC(VESA)		≤1600x1200 @60HZ
SDI Format	SDI-SMPTE 259M-C			576i @50HZ 480i @60HZ
HDSDI Format	HDSDI-SMPTE 292M SMPTE 274M/296M SMPTE 424M/425M			≤1080P @50Hz/60Hz
Input Connectors	VGA:15pin D_Sub(Female) DVI:24+1 DVI_D Composite video:BNC DP: Display Port SDI/HDSDI: BNC
Outputs
Nums/Type	1×VGA ( RGBHV) 2×DVI
VGA/DVI Format	1024×768@60Hz/75Hz 1280×1024@60Hz/75Hz 1600×1200@60Hz 1920×1080p@50Hz/60Hz
VGA Scope/Impedance	R,G,B = 0.7 V (p_p) / 75Ω
Output Connectors	VGA, , , , , , , , , , , , , , , , :15pin D_Sub(female) DVI OUT1:24+5 DVI_I DVI OUT2:24+1 DVI_D
Others
Control	Panel Button
Power	100-240VAC 60W 50/60Hz
Operating Temp	5-40 °C
Humidity	15-85%
Size	155 mm (high) ×350mm (wide) ×485mm(length)
Weight	5.6 Kg

More types:

Video processor

LVP603

LVP603S

LVP858
LVP848
LVP838

Pictures

Effect

Remarks
