Double Acting Hydraulic Jacks

FOB Price

US$ 500 - 4,800 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	FEIYAO
Model Number	FY-CLRG	Type	Hydraulic Jack
Certification	CE,ISO9001	Min Height	162mm
Max Height	724mm

Product Description

Specifications

double acting hydraulic jacks
1.Hydraulic return
2.CE certificate
3.High quality with good price
4.Factory supply directly

double acting hydraulic jacks

FEIYAO high tonnage hydraulic cylinders are designed specifically for heavy lifting solutions. Cylinder lifting capacity ranges from 50 to 1,000 tons and supplies up to 10,000 psi.

Features of double acting hydraulic jack

1.Double-acting for push and pull

2.Safety valve in retract side of cylinder, helps to prevent

3.Damage in case of accidental over-pressurization

4.Plunger wiper reduces contamination ,extending cylinder life

5.Higher capacities:1500 and 2000 ton models availble on request

Application of double acting hydraulic jack

Parameter information

Model	Capacity @700bar ton (KN)	Stroke (mm)	Effective area (cm²)		Oil capacity (cm³)		Closed height (mm)
Model	Capacity @700bar ton (KN)	Stroke (mm)	push	pull	push	pull	Closed height (mm)
FY-CLRG-502	50(539)	50	77.0	38.5	385	192	162
FY-CLRG-504		100	77.0	38.5	770	385	212
FY-CLRG-506		150	77.0	38.5	1155	577	262
FY-CLRG-508		200	77.0	38.5	1540	770	312
FY-CLRG-5010		250	77.0	38.5	1924	962	362
FY-CLRG-5012		300	77.0	38.5	2309	1155	412
FY-CLRG-1002	100(929)	50	132.7	61.9	664	309	182
FY-CLRG-1004		100	132.7	61.9	1327	619	232
FY-CLRG-1006		150	132.7	61.9	1991	928	282
FY-CLRG-1008		200	132.7	61.9	2655	1237	332
FY-CLRG-10010		250	132.7	61.9	3318	1546	382
FY-CLRG-10012		300	132.7	61.9	3982	1856	432
FY-CLRG-1502	150(1390)	50	198.6	96.5	993	482	196
FY-CLRG-1504		100	198.6	96.5	1986	965	246
FY-CLRG-1506		150	198.6	96.5	2978	1447	296
FY-CLRG-1508		200	198.6	96.5	3971	1930	346
FY-CLRG-15010		250	198.6	96.5	4964	2412	396
FY-CLRG-15012		300	198.6	96.5	5957	2895	446
FY-CLRG-2002	200(1861)	50	265.9	127.0	1330	635	216
FY-CLRG-2006		150	265.9	127.0	3989	1905	316
FY-CLRG-20012		300	265.9	127.0	7977	3809	466
FY-CLRG-2502	250(2565)	50	366.4	152.6	1832	763	235
FY-CLRG-2506		150	366.4	152.6	5497	2289	335
FY-CLRG-25012		300	366.4	152.6	10993	4578	485
FY-CLRG-3002	300(3193)	50	456.2	151.4	2281	757	312
FY-CLRG-3006		150	456.2	151.4	6843	2270	412
FY-CLRG-30012		300	456.2	151.4	13685	4541	562
FY-CLRG-4002	400(3919)	50	559.9	193.5	2800	967	375
FY-CLRG-4006		150	559.9	193.5	8399	2902	475
FY-CLRG-40012		300	559.9	193.5	16797	5804	625
FY-CLRG-5002	500(5114)	50	730.6	247.6	3653	1238	419
FY-CLRG-5006		150	730.6	247.6	10959	3713	519
FY-CLRG-50012		300	730.6	247.6	21918	7427	669
FY-CLRG-6002	600(5987)	50	855.3	295.4	4276	1477	429
FY-CLRG-6006		150	855.3	295.4	12829	4431	529
FY-CLRG-60012		300	855.3	295.4	25659	8862	679
FY-CLRG-8002	800(8234)	50	1176.3	387.0	5881	1935	474
FY-CLRG-8006		150	1176.3	387.0	17644	5806	574
FY-CLRG-80012		300	1176.3	387.0	35288	11611	724
FY-CLRG-10002	1000(10260)	50	1465.7	541.7	7329	2709	564
FY-CLRG-10006		150	1465.7	541.7	21986	8126	664
FY-CLRG-100012		300	1465.7	541.7	43972	16252	614

Accessories:

♦Seal Kits

♦Standard Couplers

♦Swivel Caps

Brief introduction of FEIYAO

Established in 1978, Jiangsu Feiyao Machinery Manufacturing factory is an professional leading manufacturer of hydraulic tools in China. Such as PLC lifiting systerm, hydraulic cylinders, torque wrench, nut splitter, flange spreader, gear pullers, hydraulic pumps and accessories etc.

Our products have been widely sold to Europe, South-east Asia and Middle East, and have got high appreciation and trust from all our customers. Whenever you need hydraulic products, please rememmber our company is always your reliable friends.

Our well-equipped facilities and excellent quality control enables us meet customers' satisfaction. Besides, we have gained CE and ISO9001 certificates.

We warmly welcome all overseas customers to talk with us about business or other cooperations.

Any phone call, E-mali, Fax from you would be a beginning of happy cooperation.
