4Ch 720P/960P HD CVI/AHD/TVI Converter Fiber Optic to BNC Digital Video Converter
- Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | chuangyuan | |
| Model Number | CY-9804C/7 |
Product Description
4Ch 720P/960P HD CVI/AHD/TVI Converter Fiber Optic to BNC Digital Video Converter
Description
AHD/HDCVI to Fiber Converter can simultaneously transmit 1-8 channels AHD/HDCVI over one multi-mode or single-mode
optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system
status. Devices are available for either standalone or rack-mount installation ,which is suitable for different working environment .
Compatible with 1280H/25f, 1280H/30f, 1280H/50f, 1280H/60f. Lossless non-compression real time transmission.
Specifications
Opitcal
Wavelength | 1310nm&1550nm |
Output Power | -8~3dBm |
Optic fiber | 50/125u multimode,62.5/125u multimode,9/125u single mode |
Rx sensitivity | -25dBm |
Optical connector | FC,ST,SC (optional) |
Distance | 0~550M (MM) / 0~20KM (SM) |
Video:
Number of Channels | 1-8 |
Input/output impedance | BNC 75Ω (unbalance) |
Standard video input/output voltage | 1.0Vp-p |
Video Bandwidth | 45MHz |
Sampling Bandwidth | 10bit |
Sampling Frequency | 108MHz |
Rise and Fall time | <0.8ns |
Optical Signal Intrinsic Jitter | <0.2 UI |
Differential Gain | < ±1.5% |
Differential Phase | < ±1° |
Connector | BNC |
Other
Power | DC5V 2A |
Power Consumption | ≤6W |
Temperature | -40ºC ~75ºC |
Humidity | 10%~90% RH |
Unit Weight(1-4CH) | 1.45KG(pair) |
Dimension(1-4CH) | 183mm×154mm×30mm |
Installation | Wall mount |
MTBF | ≥ 100000Hours |
System connection diagram
Order Information:
| Item No. | Item Name | Description |
| CY-9801C/7 | 1CH HDCVI to Fiber Converter | Video:1CH*720P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9801C/8 | 1CH HDCVI to Fiber Converter | Video:1CH*1080P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9802C/7 | 2CH HDCVI to Fiber Converter | Video:2CH*720P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9802C/8 | 2CH HDCVI to Fiber Converter | Video:2CH*1080P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9804C/7 | 4CH HDCVI to Fiber Converter | Video:4CH*720P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9804C/8 | 4CH HDCVI to Fiber Converter | Video:4CH*1080P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9808C/7 | 8CH HDCVI to Fiber Converter | Video:8CH*720P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9808C/8 | 8CH HDCVI to Fiber Converter | Video:8CH*1080P HDCVI single mode single fiber FC optical interface,20KM |
| CY-9801AH/7 | 1CH AHD to Fiber Converter | Video:1CH*720P AHD single mode single fiber FC optical interface,20KM |
| CY-9802AH/7 | 2CH AHD to Fiber Converter | Video:2CH*720P AHD single mode single fiber FC optical interface,20KM |
| CY-9804AH/7 | 4CH AHD to Fiber Converter | Video:4CH*720P AHD single mode single fiber FC optical interface,20KM |
| CY-9808AH/7 | 8CH AHD to Fiber Converter | Video:8CH*720P AHD single mode single fiber FC optical interface,20KM |
