4 channel HD TVI signal optic transceiver
- zhengzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | chuangyuan | |
| Model Number | CY-9804T/7 |
Product Description
HD TVI signal video transceiver
TVI signal optic transceiver
Overview
TVI to Fiber Converter can simultaneously transmit 1-16 channels TVI over one multimode or single-mode optical fiber. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status. Devices are available for either standalone or rack-mount installation, which is suitable for different working environment . Compatible with 720p/50,720p/60,1080p/25,1080p/30. Lossless non-compression real time transmission.
Specifications
Optical | Wavelength | 1310nm&1550nm |
Output Power | -8~3dBm | |
Optic fiber | 50/125u multimode,62.5/125u multimode,9/125u single mode | |
Rx sensitivity | -22dBm | |
Optical connector | FC,ST,SC (optional) | |
Distance | 0~550M (MM) / 0~20KM (SM) | |
Video | Number of Channels | 1~16 |
Input/output impedance | BNC 75Ω (unbalance) | |
Standard video input/output voltage | 1.0Vp-p | |
Video Bandwidth | 60MHz | |
Sampling Bandwidth | 10bit | |
Sampling Frequency | 120MHz | |
Rise and Fall time | <0.8ns | |
Optical Signal Intrinsic Jitter | <0.2 UI | |
Differential Gain | < ±1.5% | |
Differential Phase | < ±1° | |
Connector | BNC | |
Other | Power | DC5V 2A |
Power Consumption | ≤5W | |
Temperature | -40ºC ~75ºC | |
Humidity | 10%~90% RH | |
Unit Weight | 1ch :0.75kg | |
2ch/4ch/8ch: 1.5KG(pair) | ||
Dimension | 1 : 104mm×104mm×28mm | |
2ch /4ch/8ch: 183mm×154mm×30mm |
System connection diagram
