Home > Products > viscometer > six speed rotary viscometer
six speed rotary viscometer
- QINGDAO
- L/C D/P D/A
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | BAIRUIDA | |
| Model Number | ZNN-D6S |
Product Description
Outline
1, ZNN-D6S digital viscometer can be measured for each rheological parameter, draw flow curve according to multi-point measurement value, determine the liquid in the flow process flow pattern displayed by the viscosity of the chip within the instrument directly on the screen , the study of non-Newtonian fluids for a more accurate measurement for field drilling fluid rheological parameters analysis, while moving can be measured gel strength, flow index and consistency coefficient and a series of technical parameters. Conducive to safe, fast, scientific drilling needs. Easy to operate, test accurate.
2, the machine uses high-subdivision motor drive, with a stepper motor to ensure that the motor torque, speed accurate and stable. Belt transmission, low noise, easily adjusted.
3, direct digital display of measured values of viscosity and speed; (division value 0.1mPa.S, other similar products are 1mPa.S), measurement accuracy and stability, good anti-jamming sensor.
Second, the model and specifications
ZNN-D6S
Third, the main technical parameters of the instrument
The main technical parameters (Table 1)
| NO | NAME | Technical Indicators |
| 1 | power supply | 220V±5% 50Hz |
| 2 | Speed range | 3,6,100,200,300,600r/min |
| 3 | Speed ladder | 5. 10. 170,340,511,1022 S-1 |
| 4 | .measurement accuracy | 1 ~ 25 mPa • s ± 1 mPa.s (Newtonian fluid) 25mPa • s more than ± 4% (Newtonian fluid) |
| 5 | Viscosity measurement range | Newtonian fluid: 0 ~ 300mPa.s Non-Newtonian Fluid: 1 ~ 150 mPa.s Shear stress: 0 ~ 153.3Pa |
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is a viscometer, filtration device, roller furnace, high-speed mixer, Viscosity detector and other professional production and processing company, has a complete and scientific quality management system. Integrity, strength and quality of products Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is recognized by the industry. Welcome friends to visit, guidance and business negotiation
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd., founded in 2006, specializes in manufacturing series of oil slurry analytical instruments and accessories, which are widely used in major scientific research, oil drilling, oil and chemical additives in colleges.
I produced the high-quality products to meet domestic demand basis exported to many countries of the Sudan, Saudi Arabia, Iran, India and Uzbekistan.
Companies with a sound quality management system, and in accordance with API standard development and production of drilling fluids, completion fluids testing equipment.
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is a viscometer, filtration device, roller furnace, high-speed mixer, Viscosity detector and other professional production and processing company, has a complete and scientific quality management system. Integrity, strength and quality of products Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is recognized by the industry. Welcome friends to visit, guidance and business negotiation
