Road Edgeline Marker With Coating Boiler
US$ 1,300 - 3,200
/ Piece
1 Piece(Min. Order)
- Huangpu
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Factory Direct Sale Raise Reflective Road Line Marker with Paint Melter
-
Convienient Parking Lot Marking Equipment
-
Hand-guided Thermoplastic Kneader Road Marking Machine With Best Quality
-
Thermoplastic Parking lot Marking Machine
-
TOP WAY Atomatic All-in-one Marking Machine With High Quality
Quality Choice
-
Small Size Road Painting Machine
Product Details
| Condition | New | |||
| Place of Origin | Guangdong, China | Brand Name | TOP WAY | |
| Model Number | TW- FJ | Dimension(L*W*H) | 1200mm*900mm*1100mm | |
| Weight | 220kg | Features | New Design | |
| Certification | Certification | Warranty | 12 months |
Product Description
Specifications
Reflective paint Marker and Melter1. lighter and more flexible
2. Marking machine and paint heater is all-in-one
1.Brief Introduction
Reflective Paint Marker and Melter is a multi-functional hand-pushing machine integrated with hot-melting kettle and kneader marking machine, which is applicable to small but scattered and scattered projects like parting lot, school, residential neighborhood and factory. The machine is small in size and weight, easy and convenient in operation with only two operators for working.
2. Technical parameter
Outer dimensions(L*W*H) | 1200X900X1100mm |
Total weight of machine | 220KG |
Coating material tank capacity | 120KG |
Capacity of glass bead box | 25KG |
Coat thickness | 1.2--4mm |
Bead dispending method | Gear driven, Automatically Clutch |
Temperature of heated coating material | 170-220°C |
LCP cylinder norm | 15KG |
Marking width | 100,150,200,300mm,more applicable to zebra lines of 400,450mm |
3. Special Features
- Hand-driven chain drives impellers to agitate melting materials, being light and handy in operation.
- Specialized mid-pressure furnace is equipped for industrial use, which has high thermal efficiency and fast melting.
- The unique controllable switch valve of the fire road can let the operator observe the situation of the spit fire and adjust the controller of the fire road and the flame. Thus make the marking work safer and more efficient.
- Two movable extraction stacks discharge exhaust gas in time to maintain good working environment.
- Triple-layered removable covers make it convenient to clean the kettle and change melting materials in different colors.
4.Joblocation
5. Sample Lines
6. Delivery and Package
