For Paper Mill MINI Electric Segment Regulating Ball Valve
US$ 1 - 500
/ Piece
1 Piece(Min. Order)
- Shanghai/Nongbi Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
8 Inch Gate Valve Pneumatic Crossing Knife Gate Valve
-
Stainless Steel Pneumatic Steam Cutting O-Type Control Ball Valve
-
Pneumatic v Port Ball Valve, Spring Return Ball Valve, Control Ball Valves
-
Stainless Steel Pneumatic Steam Control Valve With Positioner
-
WCB Diaphragm Type Pneumatic Control Globe Valve
-
Good Quanlity Low Price Pneumatic Control Valve With Positioner
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Medium Pressure | Power | Other, Electric | |
| Material | Stainless Steel | Temperature of Media | Normal Temperature | |
| Media | Water | Port Size | DN10-DN500 | |
| Place of Origin | Zhejiang, China | Model Number | EKRV-TD100 | |
| Brand Name | Lageci | Application | General |
Product Description
|
For Paper Mill MINI Electric Segment Regulating Ball Valve
Nominal Pressure Rating:1.6 Mpa, 2.5 Mpa, 4.0Mpa Working Temperature:-20~300℃ Nominal Diameter:DN10-500mm Rated Flow Coefficient:18~19290Kv Main Material:Valve Body 304,316,316L Valve Plug 304,316,316L input Signal:4-20mADC Seal Type: Self-adjusting Stainless Steel Hard Seal(Soft Seal) Leakage:GB/T4213-2008IV Feedback signal:1.4-20mADC 2.1KΩ Potentiometer Supply voltage:220VAC
|
|
|
|
|
|
|
|
|
|
|
