Home > Products > July New Arrivals > KEXIN KX5188-A260 High Frequency Induction Hardening Equipment
KEXIN KX5188-A260 High Frequency Induction Hardening Equipment
- Any port of China
- Credit Card PayPal
You May Like
-
Made in China KX5188-A160 High Frequency Induction Hardening Equipment
-
High Quality KEXIN KX-5188A 100kw Supersonic Frequency Induction Quenching Furnace
-
KEXIN KX5188-A80 High Frequency Induction Hardening Furnace
-
High Efficency KX5188-A260 High Frequency Induction Hardening Furnace
-
New Type KX5188-A160 High Frequency Induction Quenching Machine
-
High Quality KX5188-A120 High Frequency Induction Hardening Machine
Product Details
| Condition | New | Type | Induction Furnace | |
| Usage | Other, Heat Treatment Furnace, melting,welding,hardening,annealing,forging and other heat treatment | Place of Origin | Zhejiang, China | |
| Brand Name | KEXIN | Model Number | KX-5188A260 | |
| Voltage | 380V | Power(W) | 260KVA | |
| Dimension(L*W*H) | 1150*500*820mm 900*550*500mm | Weight | 320Kg(Net Weight) | |
| Certification | CE | Warranty | One Year | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
KEXIN KX5188-A260 induction hardening equipment
Technical Features
1)Working Principle
Based on the principle of electromagnetic induction,our machine could make induced current generate inside the metal material,which is in the alternating magnetic field.Then this current could heat the material up to the melting state.
High frequency circuit are all worked as following:
Technical Parameters
Model | KX-5188A260 |
Rated Power output | 260 KVA |
Frequency rang | 30-80 KHz |
Three- phase input | Three-phase 380V /50HZ |
Current input | 5-140Ax3 |
Efficiency | 95% |
Duty cycle | 100% |
Volume(mm 3) | Host Vice-machine 1150mmx500mmx820mm 730mmx470mmx380mm |
Net Weight | 320KG |
Gross weight | 335KG |
Cooling water flow | hydraulic pressure≥0.2MPa,flow rate:5-20L/Min |
Cooling water temperature | ≤ 40°C |
Waterway of power supply | Control box: 2 inlets ,2 outlets |
Application | Quenching, annealing, conditioning saw blades, drill, turning welding standard parts of axial etc fastener local heating, forging, melting, high frequency induction heating equipment. |
Main Parts Introduction
1) Germany SIEMENS INFINEON IGBT Module(40-60KHZoscillation frequency,fast response time, high arcstability, almost spatter-free welding)
2) Japen Nichicon electrolytic capacitor(filter capacitor)
3)signal circuit, drive circuit board ,control circuit board and components are adopted:Toshiba, Hitachi,Motorola,China's top manufacturers
4)international advanced all-solid-state semiconductor power devices
5)imported transistor integrated block
6)high speed control tube
7)with perfect control,protection,alarm display circuit,machine could get full automatic tracking frequency, continuous adjustable power,safe and dependable protection,clear and accur data display and etc technical advantage
8)accoeding to the frequency and power,we offer various model of different types and design.
9) Superiority :fast heating,wide application,protable volume,easy installation,simple operation
10)Wide applicated to different kind of workpiece melting,annealing,welding,quenching,forging,hardening and other heat treatment
Application Diagram
Application Photo
Packing Details:Export standard packing,inner carton outer wooden box,double protection
Delivery Details:In stock,in one day after geting payment
Our Service
Guarantee And Off Sale Service:
1 One year guarantee for the whole machine except for the shipping cost of warramty parts.
2 24 hours technical support by mail or skype.
3 Using pictures or video to guide user in time.
4 Engineers available to service overseas.
Do not like T/T?????
ESCROW with buyer protection is supported!!!
Pls login in the following link and start easy shopping /store/317310
Related Products
Consumer feedback is our best Advesterment !!!
/store/feedback-score/317310.html
Our machine worth your trust!!!
1. Which countries your products are exported to?
Our products have been sold all over the world and with related certifications.
2. How about the warranty?
All our products have one year quality warranty, during the warranty period, the spare parts for replacement are free. And we provide life long technical support and other assistance.
3. How to install your machine?
We have installation instruction papers and videos, we will teach till you can do it yourself.
4. What about delivery?
We offer assistance on seeking best shipping way and suitable forewarder .
Any loading port and any destination city address are both ok for us
5. How about the payment terms and delivery time?
Payment terms for any machines: 100% T/T/ Western Union/ESCROW with buyer protection
We have machine in stock,so we surly will send out the machine after geting payment in one day ,if no any special adjustment requirest from clints.
6. If I have paid but can not receive the goods, how should I do?
Alibaba international website is a famous trade website and it has run very well these years.
Every supplier on it has paid a large amount membership fee, and spare much effort to manage their business well
we have Chinese business licenses which can be checked on Chinese official website or we can show it to you,and these licenses are also kept back-up on Alibaba
if we do anything illegal without honest,we would get punished very badly after you sued us.so that your concern will never appear, please do not worry
7. Is your goods has CE certificate?
Yes, all our goods has CE certificated. All machines are high quality goods.
8. What is your company: Trader or Manfacturer ?
We are manufacturer and have a big factory , warmly welcome to visit our factory and contact us.
If you need any assistance ,pls be free to contact
