15A 12mm2 Terminal Blocks
- ningbo shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | smun | |
| Model Number | 15A-12MM2 | Type | Screw Terminal |
Product Description
Specifications
Fast DeliverySmall order can be accepted
RoHS, REACH, CE
Free Samples
terminal blocks
1.brief description and advantage:
Fast Delivery
Small order can be accepted
RoHS, REACH, CE
Free Samples
2. specification
| Type: | H & U |
| Material: | PE, PP, PA |
| Galvanized Iron | |
| Working Temp: | -40°C - 65°C |
| Color: | Natural, Black, other color customized |
| Model | 3A-2,5mm2 - 100A-40mm2 |
| MOQ | Small orders can be accepted. |
| Payment term | A. L/C; T/T (Bank Transfer, Wire Transfer) |
| B. Western Union | |
| C. Paypal (For Sample Fee & Courier cost) | |
| Terms of Payment: FOB Shanghai / Ningbo; CIF, CNF, etc | |
| Delivery time | Stock is available. 15-25 working days (Up to your order quantity) for mass production. |
| Supply ability | 4×20-feet containers per week. |
| Packaging details | A. Common Packing: 10Pcs + Heat Shrink Film + Label + Export Carton |
| B. Customized Packing: OEM Label, Inner Box, Blister, etc. | |
| HS Code | 8536900000 |
| Origin country | Zhejiang, China |
| Certification | RoHS, CE |
Data Sheet of Terminal Blocks
Spec. | Length | Width | High | Brass Hole | Screw Size | Plastic | ||
mm | ||||||||
3A-2.5mm2 | 91.4 | 15.6 | 10.8 | 3 | M2.5 x 4 | PE PP PA | ||
5A-4mm2 | 110 | 15.6 | 10.8 | 3 | M2.5 x 4 | PE PP PA | ||
6A-6mm2 | 112.5 | 15.5 | 12.8 | 3.3 | M3.0 x 5 | PE PP PA | ||
10A-10mm2 | 128 | 20.6 | 15 | 4.2 | M3.0 x 6 | PE PP PA | ||
15A-12mm2 | 137.3 | 22.5 | 16.6 | 4.5 | M3.5 x 7 | PE PP PA | ||
20A-14mm2 | 137.5 | 22.7 | 17.7 | 4.7 | M4.0 x 6.5 | PE PP PA | ||
30A-16mm2 | 164.5 | 25.3 | 19 | 5.6 | M4.0 x 7 | PE PP PA | ||
60A-25mm2 | 185.5 | 29.2 | 24 | 6.6 | M4.0 x 9 | PE PP PA | ||
80A-35mm2 | 204.5 | 32.6 | 27.2 | 7.8 | M5.0 x 11 | PE PP PA | ||
100-40mm2 | 250 | 45.6 | 30.6 | 9 | M6.0 x 12 | PE PP PA | ||
3.poducts
A. Common Packing: 10Pcs + Heat Shrink Film + Label + Export Carton
B. Customized Packing: OEM Label, Inner Box, Blister, etc.
