Home > Products > water well drilling rig > KQZ200D Portable Irrigation Well Drilling Rig
KQZ200D Portable Irrigation Well Drilling Rig
- Shanghai Wuhan
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Hubei, China | Brand Name | Shoukai | |
| Model Number | KQZ200D | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KQZ200D portable irrigation well drilling rig
1.Safe and stable travelling system
2.Powerful and reliable engine
3.Multi-angle operation,small and easy operation
4.The small water drilling rig machineis suitable for industrial and agriculture water well,the dill hole is big and deep,drilling speed is fast,easy to move.
5.The water drilling rig is universally used in the railway, highway, and bridge constructions of industry and is a very environmental-friendly mechanical product for urban construction.
6.This water drilling rig for sale is very popular in using in any kind of groundwork constructions.which is more powerful and functional in worksite. This drilling machine is thoroughly matched with the high quality of devices.
7.In the drilling operation, it has a high working efficiency, strong ability to break, without shock or noise, and a high degree of mechanization.
| Model No: | KQZ100-1 | KQZ100-2 | KQZ150D | KQZ200D |
| Diameter of hole: | 80-120mm | 80-150mm | 80-219mm | 80-219mm |
| Drilling depth: | 30-60m | 30-60m | 100-150m | 100-200m |
| Air consumption: | 6m³/min | 6 m³/min | 14.5 m³/min | 14.5-26 m³/min |
| Working pressure: | 5-8 bar | 5-8 bar | 8-21 bar | 8-22bar |
| Rotation speed: | 0-78 rpm | 0-78 rpm | 0-78 rpm | 0-52 rpm |
| Incline angle of borehole: | 45°-85° | 45°-90° | 45°-90° | 22°-90° |
| Pushing Length: | 1000mm | 1000mm | 1000mm | 1500mm |
| Motor Power: | 2.2KW,3KW,4KW | 4-5.5KW | 7.5-11KW | 11KW |
