SKD80 small DTH mining drilling rig machine

FOB Price

USD $1,400 - $1,600 / Set

5 Sets(Min.Order)

Port Wuhan or any port in China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hubei, China		Brand Name	Shoukai
Model Number	SKD80		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

1, It is a new rock drilling equipment with energy saving, high efficiency designed by ourselves.

2, It is widely applied to larg, medium and small mining, road, national defence, water conservancy, big stone project and side slope working, etc for blasthole drilling. It's also a necessary rock drilling equipment for earlier explore of open air mine.

3, It is specially useful for rugged and accidented areas where other DTH drilling rig can not work normally.

4, This drilling rig features compact structure, easy operating, fast drilling, high efficiency, easy to disassemble and very convenience for carrying.

model	SKD80
bore diameter	80~120mm
bore depth	≥15m
rock hardness	≥20
rotating speed (without load)	110r/min
working air pressure	0.5~0.7Mpa
air consumption	≥6m^{3 _{/ min}}
propulsion cylinder stroke	1070mm
rated rotating speed	1440r/min
electric motor power	4kw
electric motor voltage	380V
drilling rod length	1025mm
recommended matched power	3.5 / 7
