Home > Products > man portable dth drilling rig > Drilling Rig Manufacturers SKD70 Dth Man Portable Drill Rig
Drilling Rig Manufacturers SKD70 Dth Man Portable Drill Rig
Negotiable
/ Set
5 Sets(Min. Order)
- Shanghai Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Drilling Rig Manufacturers SKD100 Dth Man Portable Drill Rig
-
SKD80 Electric Dth Man Portable Drilling Rig for Blasting
-
Portable Electric Stone Quarry Drilling Machine for Sale
-
SKD100 Electric Dth Borehole Drilling Rig for Rock Blasting And Construction
-
SKQ100 Pneumatic Dth Borehole Drilling Rig
-
SKD70 Portable Electric Dth Borehole Drilling Rig
Product Details
| Place of Origin | Hubei, China | Brand Name | Shoukai | |
| Model Number | SKD70 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1, It is a new rock drilling equipment with energy saving, high efficiency designed by ourselves.
2, It is widely applied to larg, medium and small mining, road, national defence, water conservancy, big stone project and side slope working, etc for blasthole drilling. It's also a necessary rock drilling equipment for earlier explore of open air mine.
3, It is specially useful for rugged and accidented areas where other DTH drilling rig can not work normally.
4, This drilling rig features compact structure, easy operating, fast drilling, high efficiency, easy to disassemble and very convenience for carrying.
| model | SKD70 |
| bore diameter | 60~80mm |
| bore depth | 15m |
| rock hardness | ≥20 |
| rotating speed (without load) | 110r/min |
| working air pressure | 0.5~0.7Mpa |
| air consumption | ≥3.5m3 / min |
| propulsion cylinder stroke | 1070mm |
| lifting force | 3600N |
| electric motor power | 3kw |
| electric motor voltage | 380V |
| drilling rod length | 1025mm |
| engine | electric motor |
| recommended matched power | 3.5 / 7 |
