Used SCMC SDR280 Rotary Drilling Rig
- Shanghai or Tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | SCMC | |
| Model Number | SDR280 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Name
Used SCMC SDR280 Rotary Drilling Rig
Product Specification
| Output Torque | 280 KN.m |
| Max. drilling depth | 73/(87)m |
| Max. drilling diameter | 2500mm |
| Speed of rotation | 6-22r/min |
| Engine | Cummins |
| Engine Model | QSm11-C400 |
| Engine power | 298KW |
| Engine rating rotate speed | 2100r/min |
| Engine conforms to Exhaust Emission standard | TIER3 |
| Crowd pressure Max. | 180KN |
| Crowd pull Max. | 220KN |
| Crowd Cylinder stroke | 6000mm |
| Main winch line Max. force | 280KN |
| Main winch line Max. speed | 60m/mim |
| Auxiliary winch Max. force | 80KN |
| Auxiliary winch line Max. speed | 50m/min |
| Rotating platform Slewing speed | 2r/min |
| Mast Rake side/forwards/backwards | ±3°/5°/15° |
| Shipping position L×W×H | 17500×3310×3458mm |
| Operating position L×W×H | 8835×4400×23300mm |
| Travel speed | 1.5km/h |
| Climbing ability | 35% |
| Operating mass | 83000kg |
| Ground pressure | 110kpa |
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd is located in xuzhou, the earliest place to research and development, production base of rotary drilling rigs in China. The company is specialized in selling new rotary drilling rigs, full -rotary drilling rigs and other piling machine; has complete industrial chain of researching and development, manufacturing and marketing various buckets, supply spare parts; also engages in evaluating and trading second-hand rotary drilling rigs.
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd has many year's technical advantages, professional and experienced maintenance team; with moving maintenance shop--special vehicle for rigs field service; and advanced testing equipment, professional repairing workshop, spare parts warehouse, perfect testing methods and management system, all of these ensure the quality of our service and woke efficiency.
Professional rotary drillng rig service group is good at remanufacture and repairment.Complete product range including R412HD,R516,R518I,R518II,R518III,R622.
