Home > Products > ARC welding machine > Portable MMA ARC 140 IGBT inverter welding machine
Portable MMA ARC 140 IGBT inverter welding machine
- Shanghai shenzhen guangzhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Sichuan, China | |
| Brand Name | EP Welding | Model Number | EP ARC-1400 | |
| Arc Current | 140A | Pulse Frequency | 50HZ | |
| Pilot Arc Current | 10A | Rated Duty Cycle | 60% | |
| Motor Type | AC Motor | Dimensions | 360*200*290mm | |
| Usage | Welding | Voltage | 230V | |
| Power(W) | 5900 | Certification | CE; CCC; ISO9001 | |
| Warranty | 12 months | After-sales Service Provided | No overseas service provided |
Product Description
Portable MMA ARC 140 IGBT inverter welder
Top Features:
1. Advanced IGBT Inverter technolog and Imported IGBT components;
2. Strong Fan can reduce noise and dust inside the machine;
3. Smooth arc can make it easy to weld;
4. Automatic Hot Start boosts the current during starting to make striking an arc easier;
5. Easy to operate - selector switch can quickly adjust the welding current;
6. Overvoltage protection: No damage to machine caused if inadvertently connected to high voltage.
Specifications: Portable MMA ARC 140 IGBT inverter welder.
| Model | ARC-120 | ARC-140 | ARC-160 | ARC-180 | ARC-200 |
| Related power | Single Phase AC 230V±10% 50HZ | ||||
| Related input current (A) | 18 | 20 | 22 | 24 | 26 |
| No-load voltage (V) | 85 | 85 | 85 | 85 | 85 |
| Output current range (A) | 10-120A | 10-140A | 10-160A | 10-180A | 10-200A |
| N.W (KGS) | 3.5 | 4.5 | 5 | 5.5 | 6 |
| Related duty cycle (%) | 35% | 35% | 35% | 35% | 35% |
| Insulation class | H | H | H | H | H |
| Accessories included | Standard accessories: a. Electrode holder L=3m; b. Earth cable L=2m; c. Quick plug 2pcs; d.Welding mask, Brush & hammer. | ||||
| Electrode diameter | 1.6-3.2MM | 1.6-3.2MM | 1.6-4MM | 1.6-4MM | 1.6-5MM |
Quality control start from every components!
Standard Accessories: a. Electrode holder L=3m; b. Earth cable L=2m; c. Quick plug 2pcs; d.Welding mask, Brush & hammer.
Application industries: Portable MMA ARC 140 IGBT inverter welder suit for welding all kinds of basic welding rod.
1. Warranty: Free 1 year warranty for all EXPERT welding machine;
2. Quick response: Experianced professional sales support in-24hours response for your questions and product inquiry;
3. Spare parts: 1 set of free spare parts(in our standards) will be provided for replacement for every 20pcs machines;
4. Technical Support online: Maintenance manual or video service, We provide online support according to your picture or video feedback. Customized after-sales service according to different conditions;
5. Training: Free onsite Product training is available at our factory if client request.
Why choose EXPERT brand welding machine?
1. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date;
2. We use IMPORTED COMPONENTS for mostly of our welders;
3. We adopt IGBT Technology to decrease failure rate and it is convenient to repair the machine and reduce the cost of repairing.
