Home > Products > Intelligent Switching > RAMWAY RY-IS-60/80A Smart Home, the Guide Rail Type, Wireless Remote Control Switch
RAMWAY RY-IS-60/80A Smart Home, the Guide Rail Type, Wireless Remote Control Switch
- Shenzhen
- T/T Credit Card
You May Like
-
RAMWAY RY-IS-60/80A Outdoor Switch, Wireless Remote Control Switch, Smart Home
-
RAMWAY RY-IS-60/80A Outdoor Switch, Wireless Remote Control Switch, the Guide Rail Type
-
RAMWAY RY-IS-60/80A ITS, OBU, ETC
-
RAMWAY RY-IS-60/80A ETC, OBU, Modular
-
RAMWAY RY-IS-60/80A Outdoor Switch, OBU, ETC
-
RAMWAY RY-IS-60/80A Modular, the Guide Rail Type, Smart Switches
Product Details
| Place of Origin | Guangxi, China | Brand Name | RAMWAY | |
| Model Number | RAMWAY RY-IS-60/80A | Theory | Electromagnetic Relay | |
| Usage | Protective | Size | Miniature | |
| Protect Feature | Epoxy | Contact Load | High Power |
Product Description
CONTACT DATA
Contact form | 1A & 1B |
Contact resistance | Max.1mΩ(12VDC 1A) |
Contact material | Silver alloy |
Resistance load | 90A/250VAC |
Max. switching current | 90A |
Max. switching power | 22500VA |
Electrical life | 1x104 cycles |
Mechanical life | 1x106 cycles |
CHARACTERISTICS
Insulation resistance | 1000MΩ (at 500VDC) | |
Dielectric strength | Between contact & coil | 4000VAC 1min |
Between contacts | 2000VAC 1min | |
Operation time | Max.20ms | |
Comeback time | Max.20ms | |
Vibration resistance | 10-55Hz, 1.5mm(DA) | |
Humidity | 98%RH, +40°C | |
Termination | PCB&QQC | |
Weight | 42g | |
COIL DATA
Nominal coil voltage | Single coil resistance | Dual coil resistance |
6VDC | 36Ω | - |
9VDC | 75Ω | - |
12VDC | 120Ω | - |
24VDC | 550Ω | - |
ORDER INFO
----------------------- | DS903C | A | 90A | 6V | - | T |
Relay Model |
|
|
|
|
|
|
Connecting form | A/B/C/D/E | |||||
Terminal Type | 80A 90A | |||||
Coil Voltage | 6/9/12/24VDC | |||||
Coil Type | Single-No mark | |||||
Contact Material | D – AgCdO12 T – AgSnO2 | |||||
Advantages
1.Only need pulse excitation and can be single coil working.
2.Small volume and QC installation.
3.Low power consumption and strong load capacity.
4.Security, reliable and long working life.
Note
1.Free SAMPLE for testing(1-5pcs);
2.Factory price, FOB Shenzhen;
3.Welding accessories according to clients requirement;
4.If clients have special requirement on size of other dimension, please sent us the details or drawings;
5.Delivery: within 30 days after receiving the payment(this is for MOQ, any problem or special requests, contact us).
Usage
Be fit for Prepayment energy Meter and AMR system Combination switch, reactive power compensation devices and automatic control.
