RAMWAY RY-IS-60/80A Electric Switch12v, Switch Boxes, ETC

FOB Price

US$ 5 - 6.5 / Piece

200 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangxi, China	Brand Name	RAMWAY
Model Number	RAMWAY RY-IS-60/80A	Theory	Electromagnetic Relay
Usage	Protective	Size	Miniature
Protect Feature	Epoxy	Contact Load	High Power

Product Description

CONTACT DATA

Contact form	1A & 1B
Contact resistance	Max.1mΩ(12VDC 1A)
Contact material	Silver alloy
Resistance load	90A/250VAC
Max. switching current	90A
Max. switching power	22500VA
Electrical life	1x10⁴ cycles
Mechanical life	1x10⁶ cycles

CHARACTERISTICS

Insulation resistance		1000MΩ (at 500VDC)
Dielectric strength	Between contact & coil	4000VAC 1min
	Between contacts	2000VAC 1min
Operation time		Max.20ms
Comeback time		Max.20ms
Vibration resistance		10-55Hz, 1.5mm(DA)
Humidity		98%RH, +40°C
Termination		PCB&QQC
Weight		42g

COIL DATA

Nominal coil voltage	Single coil resistance	Dual coil resistance
6VDC	36Ω	-
9VDC	75Ω	-
12VDC	120Ω	-
24VDC	550Ω	-

ORDER INFO

-----------------------	DS903C	A	90A	6V	-	T
Relay Model
Connecting form	A/B/C/D/E
Terminal Type	80A 90A
Coil Voltage	6/9/12/24VDC
Coil Type	Single-No mark
Contact Material	D – AgCdO₁₂ T – AgSnO₂

Advantages

1.Only need pulse excitation and can be single coil working.

2.Small volume and QC installation.

3.Low power consumption and strong load capacity.

4.Security, reliable and long working life.

Note

1.Free SAMPLE for testing(1-5pcs);

2.Factory price, FOB Shenzhen;

3.Welding accessories according to clients requirement;

4.If clients have special requirement on size of other dimension, please sent us the details or drawings;

5.Delivery: within 30 days after receiving the payment(this is for MOQ, any problem or special requests, contact us).

Usage

Be fit for Prepayment energy Meter and AMR system Combination switch, reactive power compensation devices and automatic control.

OUR FACTORY

PACKING
