SIEN GG Series150/300/450/600 Lollipop Line

FOB Price

US$ 50,000 - 100,000 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shanghai, China
Brand Name	sien	Model Number	SE-III
Application	Candy	Voltage	380V/50HZ
Power(W)	45KW	Weight	4000kg
Dimension(LWH)	1500017002400mm	Certification	CE ISO9001
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

SIEN GG Series150/300/450/600 lollipop line

Sien automatic lollipop line is an advanced candy machine at present time,which integrates mechanical and electric all in one.This machine has the features of high output,high quality,various types,convenient operation,compact structure,and highly automatic PLC control.This machine can produce solid, swirls, two colour striped and centre-filled lollipops. The product of this machine possess transparent color, smooth surface and nice taste,being popular with both domestic and overseas lollipop line buyer.

1.Function

(1) Continuous vacuum syrup cooking and automatic temperature control.

(2) Neat and clean appearance, reasonable structure.

(3) High transparency, easy and convenient operation.

(4) It can be equipped with pigment, flavor and acid liquor quantitative charging mixing device.

2.Technological Process

Sugar, Grape syrup, Spice Mix → Sugar melting pot → Syrup pump → Syrup storage tank → Vacuum continuous micro-film cooker → Multi Function Lollipop Servo depositing Unit Machine(depositing, cooling, forming) → Packaging

3.Parameters

Model	SE150B	SE300B	SE450B	SE600B
Output	150kg/h	300kg/h	450kg/h	600kg/h
Specification of the stick	60-100mm	60-100mm	60-100mm	60-100mm
Depositing speed	25-30n/min	25-30n/min	25-30n/min	25-30n/min
Steam requirement	250kg/h 0.5-0.8Mpa	300kg/h 0.5-0.8Mpa	400kg/h 0.5-0.8Mpa	500kg/h 0.5-0.8Mpa
Compressed air requirement	0.6m3/min 0.4-0.6Mpa	0.6m3/min 0.4-0.6Mpa	0.6m3/min 0.4-0.6Mpa	0.6m3/min 0.4-0.6Mpa
Working condition	Temp: 20-25°C Humidity: 55%	Temp: 20-25°C Humidity: 55%	Temp: 20-25°C Humidity: 55%	Temp: 20-25°C Humidity: 55%
Total power	18KW/380V	27KW/380V	34KW/380V	38KW/380V
Total length	17m	19m	18m	22m
Gross weight	3500kg	4000kg	4500kg	5000kg
