Plastic Bottle Unscrambling Machine/Unscrambler Equipment

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Plastic Bottle Unscrambling Machine/Unscrambler Equipment
1.auto bottle unscrambler
2.0.25-2L bottle
3.9000-12000b/h
4.CE

Plastic Bottle Unscrambling Machine/Unscrambler Equipment

Working principle:
When the bottle elevator is started, the disordered bottles will be transferred on top of umbrella shape tower, and then

fall into bottle ascending-descending devices.

The bottle ascendidescending devices will push bottles into bottle dropping grooves under the action of cam.

Then the ordered bottles will be sent out through planet wheel into air conveyor. Planet wheel is connected with motor main axis by synchronous belt.

Main Technical Technology

1	Number of working positions	16
2	Rationed capacity	10000 bottles /hour
3	Max .capacity	12000 bottles/ hour
4	Air pressure	0.7MPa
5	Air consumption	1.5M3/ min
6	Applicable bottles. diameter	50-96MM,
7	Applicable bottles. Height	165-300MM
8	Main motor	1.5KW
9	Lifting motor	0.75KW
10	Fan	2.2KW
11	Dimension	Approx 2200×2340mm (diameter × height)
12	Weight	Approx 3600 Kg

Any further info for Plastic Bottle Unscrambling Machine/Unscrambler Equipment , pls contact me.
