Home > Products > bottle sorting machine > High Speed Water Bottle Unscrambler Machine/Equipment
High Speed Water Bottle Unscrambler Machine/Equipment
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | customized | Power | 4.5KW | |
| Place of Origin | Jiangsu, China | Brand Name | HUASHENG | |
| Model Number | LP | Weight | 3600kg | |
| Dimension(L*W*H) | D2200*3400 | Certification | CE,ISO,UL | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Huasheng beverage machinery Co., Ltd. was established in 1994, It's a professional manufacturer of liquid food and beverage equipment.
They have good experience especially in filling and capping technology.and they provide customized service and turnkey project.
The products scope as below: PET bottle filling machine, Glass bottle filling machine, Capping machine, Bottle washing machine, Water treatment, Oil filling machine/piston filler, Other bottle filling machine, Labeling machine, wrap packing machine, bottle unscrambler, and some drinks production line auxiliary. |
High Speed Water Bottle Unscrambler Machine/Equipment
Brif-
This unscrambler machine/unscrambling machine applied to Round/square/flat PET bottle, water bottle unscrambling, carbonated water bottle unscrambler, juice bottle unscrambler...
Working principle:
When the bottle elevator is started, the disordered bottles will be transferred on top of umbrella shape tower, and then
fall into bottle ascending-descending devices.
The bottle ascendidescending devices will push bottles into bottle dropping grooves under the action of cam.
Then the ordered bottles will be sent out through planet wheel into air conveyor. Planet wheel is connected with motor main axis by synchronous belt.
Main Technical Technology
1 | Number of working positions
| 16 |
2 | Rationed capacity | 10000 bottles /hour |
3 | Max .capacity | 12000 bottles/ hour |
4 | Air pressure | 0.7MPa |
5 | Air consumption | 1.5M3/ min |
6 | Applicable bottles. diameter | 50-96MM, |
7 | Applicable bottles. Height | 165-300MM |
8 | Main motor | 1.5KW |
9 | Lifting motor | 0.75KW |
10 | Fan | 2.2KW |
11 | Dimension | Approx Φ2200×2340mm (diameter × height |
12 | Weight | Approx 3600 Kg |
Any further info for High Speed Water Bottle Unscrambler Machine/Equipment , pls contact me.
Contact Us
- Zhangjiagang Huasheng Beverage Machinery Co., Ltd.
- Contact nameHuasheng Fan Chat Now
- Phone86-512-58661098
- AddressYongle Village, Leyu Town
