Home > Products > CNC spring coiling machine > GJ-120A professional 12mm computer spring roll machine
GJ-120A professional 12mm computer spring roll machine
- Shenzhen Port
- T/T D/P D/A
You May Like
-
GJ-60A Dongguan high speed CNC pressure spring machine
-
Dongguan low price 2 axis cnc helical coil spring machine
-
GJ-40B high quality automatic spring coiler
-
GJ-20A cnc automationc spring coiler for slanted spring wave spring
-
GJ-80A Dongguan computer compression spring machine
-
GJ-40A 4 axis cnc automatic tower spring machine
Product Details
| Place of Origin | Guangdong, China | Brand Name | Guangjin | |
| Model Number | GJ-120A | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Features of Spring roll machine(GJ-120A)
1, The hardware system highly integrated,so that failure rate is reduced to a minimum and the stability is improving greatly.
2, Don’t need to stop the machine can use hand- shaking wheel at anytime to change the speed of the machine
3, Simple repetitive programming cooperates with the probe speed can be set for producing flat springs etc., manifold cycles
4, ensure that the 100% Taiwan imported, superior quality
Technical Parameters
Model | GJ-120A |
Axis Count | 5 axis |
Wire Size Range | Φ0.15~ Φ2.0mm |
Max Feeding Length | Unlimited |
Wind direction | Right and Left Hand |
Max Feeding Speed | 0~150m/min |
Min Setting Value | 0.01mm |
Max Setting Value | 9999.99mm |
Outside Diameter | ≤150.00mm |
Cam Min Seting Value | 0.1° |
Cam Max Setting Value | 359.9° |
Wire Feed Servo Motor | 37kw |
Cutter servo motor | 7kw*2 |
Pitch Servo motor | 2.7kw |
Cam Motor | 7w |
Dimension(LxWxH) | 2720x1820x2520mm |
Weight | 9500kg |
Service
1, 11years of experience in this line
2, All machines recieve good comments from customer
3, Independent R&D ability
4, Always happy to serve and work with our customer
Place order to us
Package
Company profile
Dongguan city guang jin CNC equipment co., LTD Is engaged in the computer spring machine, compression spring machine, professional production, research and development, design, sales, service as one of the famous high-tech enterprises in guangdong province, product marketing in Europe and southeast Asia and other countries and regions,deeply domestic and foreign customers favor!"Guang jin" can be the development and manufacture according to customer's personalized needs of different specifications of the models.
