Split Pressure Solar Water Heater

The separate pressurized solar water heater compose of solar collector, storage tank, controller, working station and installation parts.

Please note, we have got the CE and CCC certificates for all of our products

Specification:

1.      Vacuum tubes: Common tubes or Three-high tubes , with heat pipe in it

2.      Outer tank: Steel plate , thickness: 0.326mm

3.      Inner tank:  food grade stainless steel SUS304-2B, thickness: 1.2 to 1.5mm

4.      Tank capacity: 100L to 500L

5.      Pressure bearing: 0.6 bar

6.      Insulation layer: Polyurethane foam , thickness: 50mm to 60mm

7.      Support: Galvanized plate or stainless steel, thickness: 1.2mm to 1.5mm

8.      Heat preservation: 72 to 80 hours

9.      Hail resistance: 25mm

Feature:
1) Collector separates with the storage tank. The tank can be put anywhere
    of the house
2) And the collector can be put on both tilted roof and flat roof
3) Module design, arbitrary combination, harmony with the building perfectly
4) Intelligent control and automatic operation
5) Anti-freeze: no water inside the tubes when it works
6) The system controller has the anti-freezing function is that the temperature
     circulation will operate while it reaches the fixed temperature
7) Multifunction: Bathing, washing, domestic heating
8) Workable at anytime and enjoyable

-----------------------------WHY JINENG SOLAR----------------------

Primary Competitive Advantages:

1) Solar Keymark, CE, CCC, ISO Certificed

2) Strict Qality Control, Pompt Dlivery

3) Satisfied After-sale Service

4) Environmental Protection

5) 10 Year’s Experience

6) OEM Accepted
